Juniper SFP-1FE-FX | SFP Transceiver, 100BASE-FX, 1310nm, MMF, 2km, LC

Name: Juniper SFP-1FE-FX | SFP Transceiver, 100BASE-FX, 1310nm, MMF, 2km, LC
Brand: Juniper
SKU: SFP-1FE-FX
Price: 238.91 AUD
Availability: BackOrder

Authorised Juniper Partner

SKU:SFP-1FE-FX

Stock Status: Enquire

$238.91 inc. GST

$217.19 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Juniper SFP-1FE-FX is a 100BASE-FX Fast Ethernet SFP transceiver for fibre links over multimode fibre. It operates at 1310nm over 62.5/125 multimode fibre with a reach of up to 2km and terminates in an LC duplex connector. The extended temperature rating suits deployments where standard optics are not specified.

This hot-pluggable SFP optic is designed for Juniper routing platforms, with the MX240, MX480 and MX960 among the supported chassis and the MX80, ACX1100 and ACX2200 also listed as compatible. It provides a straightforward way to add 100 Mbps fibre connectivity to Juniper routers.

Features

- Hot-pluggable SFP optic for Fast Ethernet fibre links
- Supports 100BASE-FX over multimode fibre up to 2 km
- LC duplex connector for standard fibre patching
- Extended temperature rating for demanding environments
- Compatible with multiple Juniper routing platforms in the MX and ACX series
- Listed in the Juniper Hardware Compatibility Tool under Transceivers

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: SFP-1FE-FX (740-021487-01)
- Interface standard: 100BASE-FX Fast Ethernet
- Data rate: 100 Mbps
- Form factor: SFP
- Wavelength: 1310 nm
- Fibre type: Multimode fibre (MMF), 62.5/125 µm
- Maximum reach: 2 km
- Connector: LC duplex
- Operating temperature: extended (-5 to 70 °C)
- Supported platforms: MX240, MX480, MX960
- Also listed as supported on: MX80, ACX1100, ACX2200

FAQs

Q: What speed does the SFP-1FE-FX support?
A: It supports 100BASE-FX Fast Ethernet at 100 Mbps. It is not a Gigabit optic.

Q: What type of fibre does it use?
A: It is designed for 62.5/125 micron multimode fibre at 1310nm with LC duplex connectors, for links up to 2km.

Q: Which Juniper platforms is it compatible with?
A: The Juniper datasheet lists the MX240, MX480 and MX960. The MX80, ACX1100 and ACX2200 are also listed as supported.

Q: Is this module hot-pluggable?
A: Yes, it is a hot-pluggable SFP optic and can be installed or removed while the host platform is powered.

Q: Can I use it for single-mode fibre links?
A: No. This optic is for multimode fibre. Single-mode links need a different Juniper SFP designed for single-mode fibre.

Q: Does it have an extended temperature rating?
A: Yes, it is an extended temperature SFP rated for -5 to 70 °C.
