Juniper QSFP-400G-DR4-2 | QSFP112 400GBASE-DR4 Transceiver, SMF, 2km, MPO-12

Juniper QSFP-400G-DR4-2 | QSFP112 400GBASE-DR4 Transceiver, SMF, 2km, MPO-12

Authorised Juniper Partner

SKU:QSFP-400G-DR4-2

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Juniper QSFP-400G-DR4-2 is a QSFP112 400GBASE-DR4 optical transceiver for single-mode fibre, delivering 400GbE over four 100G PAM4 lanes at 1310 nm. It reaches up to 2km over OS2 fibre with an MPO-12 connector and is rated for the standard temperature range of 0 to 70 degrees C, making it well suited to data centre spine-leaf and AI/ML fabrics.

This module is designed for Juniper QFX and PTX platforms with 400GbE QSFP112 ports. The compact QSFP112 form factor supports high-density 400G deployments, and the MPO-12 interface also suits breakout and parallel-fibre cabling designs.

Features

- QSFP112 compact form factor with four 112 Gbps electrical lanes
- 400GBASE-DR4 using 4-lane PAM4 optical signalling at 1310 nm
- Extended 2km reach over OS2 single-mode fibre
- Designed for Juniper QFX and PTX platforms with 400GbE QSFP112 ports

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP112
- Standard: 400GBASE-DR4, 4 x 100G PAM4 lanes
- Wavelength: 1310 nm
- Fibre type: single-mode (OS2)
- Reach: up to 2km
- Connector: MPO-12
- Temperature range: 0 to 70 degrees C (standard temperature)

FAQs

Q: What fibre type does the QSFP-400G-DR4-2 require?
A: It operates over single-mode fibre (OS2) terminated with an MPO-12 connector, with a reach of up to 2km.

Q: Which Juniper platforms is this transceiver designed for?
A: It is designed for Juniper QFX and PTX platforms that provide 400GbE QSFP112 ports.

Q: What temperature range does this module support?
A: This is the standard temperature variant, rated for 0 to 70 degrees C.

Q: How does 400GBASE-DR4 deliver 400GbE?
A: It uses four parallel 100G PAM4 lanes at 1310 nm, with each lane carried on its own fibre pair via the MPO-12 connector.

Q: What is this transceiver typically used for?
A: It is intended for data centre spine-leaf and AI/ML fabrics where short-reach 400GbE links over single-mode fibre are needed.
