Description

The EX9204-CHAS3-S is an empty 4-slot modular switch chassis with a passive midplane (Chassis 3), designed for the Juniper EX9204 core Ethernet switch. It is a 5U rack-mountable platform for campus and data centre core deployments, with hot-swappable modules and a single-tier, low-latency switch fabric architecture.

This is the chassis only. Line cards, routing engines, switch fabric modules, fan trays and power supplies are ordered separately. The passive midplane carries control and management signals over independent paths, and the platform runs Junos OS. It is compatible with the EX9200-RE2 Routing Engine, EX9200-SF3 Switch Fabric and 2,520 W AC or 4,100 W DC power supplies.

Features

- Modular design with hot-swap module replacement
- Passive midplane distributes control and management signals over independent paths
- Part of the EX9200 line: a programmable, flexible and scalable core for campus and data centre
- No head-of-line blocking, single-tier low-latency switch fabric architecture
- Runs Junos OS

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 4-slot modular chassis (EX9204) with passive midplane
- Chassis only, modules ordered separately
- Rack-mountable, 5U
- Height 22.1 cm, depth 70.5 cm
- 2 x line card slots and 2 x switch fabric slots
- Hot-swappable modules
- Compliance includes NEBS Level 3, cUL and TUV GS
- Compatible with EX9200-RE2 Routing Engine, EX9200-SF3 Switch Fabric, 2,520 W AC and 4,100 W DC PSUs

FAQs

Q: Does the EX9204-CHAS3-S include line cards or a routing engine?
A: No. This is the empty chassis with a passive midplane only. Line cards, routing engines, switch fabric modules, fan trays and power supplies are ordered separately.

Q: Which routing engine and switch fabric modules are compatible?
A: The chassis is compatible with the EX9200-RE2 Routing Engine and EX9200-SF3 Switch Fabric modules.

Q: Which power supplies can be used with this chassis?
A: It supports 2,520 W AC and 4,100 W DC power supplies as listed in the EX9200 system configurations.

Q: How many rack units does the EX9204 chassis occupy?
A: The EX9204 chassis is a 5U rack-mountable unit.

Q: Are the modules hot-swappable?
A: Yes. The modular design supports hot-swappable module replacement.

Q: What operating system does the EX9204 run?
A: The EX9200 platform runs Junos OS.
