HPE JG325B | X140 40G QSFP+ Transceiver, MPO SR4, 850 nm, Multi-Mode

Name: HPE JG325B | X140 40G QSFP+ Transceiver, MPO SR4, 850 nm, Multi-Mode
Brand: HPE
SKU: JG325B
Price: 5682.53 AUD
Availability: BackOrder

Authorised HPE Partner

SKU:JG325B

Stock Status: Enquire

$5,682.53 inc. GST

$5,165.94 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The HPE X140 40G QSFP+ MPO SR4 transceiver is a 40GBASE-SR4 optical module that delivers 40Gbps over multi-mode fibre at 850 nm. It uses a 12-fibre MPO connector and suits short-reach links between data centre switches and other high-throughput connections where 40G density matters.

This hot-pluggable QSFP+ module supports OM3 and OM4 multi-mode cabling, with reach of up to 100 m on OM3 and 150 m on OM4. It is MSA compliant and designed for use with compatible HPE switches, so ports can be added or replaced without powering down the host device.

Features

- 40GBASE-SR4 optics for short-reach links between data centre switches
- Hot-pluggable QSFP+ module for easy installation and replacement
- MSA compliant
- Parallel multi-mode fibre operation with an MPO connector

Warranty

Hewlett Packard Enterprise (HPE) offers a standard limited hardware warranty on its products, with coverage periods varying by product line. For instance, HPE ProLiant servers typically come with a 1 to 3-year limited warranty, while other products may have different durations.
Extended Warranty Options via IP Trading:
IP Trading offers tailored extended warranty solutions and support packages for HPE products, ensuring your IT infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Replaces (older part #)

FAQs

Technical Specifications

- Form factor: QSFP+
- Data rate: 40 Gbps
- Standard: 40GBASE-SR4
- Wavelength: 850 nm
- Connector: MPO (12-fibre)
- Fibre type: Multi-mode (OM3/OM4)
- Reach: up to 100 m on OM3, 150 m on OM4
- Hot-plug support: Yes
- Certification: MSA
- Operating temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Operating relative humidity: 10 to 80 %
- Weight: 180 g

Replaces (older part #)

JG325A

FAQs

Q: What fibre type does this transceiver require?
A: It operates over multi-mode fibre, OM3 or OM4, terminated with a 12-fibre MPO connector.

Q: What is the maximum link distance?
A: Up to 100 m on OM3 fibre and up to 150 m on OM4 fibre.

Q: Is this module hot-pluggable?
A: Yes. It is a hot-pluggable QSFP+ module and can be installed or removed while the host switch is powered.

Q: What wavelength does it use?
A: It transmits at 850 nm as defined by the 40GBASE-SR4 standard.

Q: Can I use it with single-mode fibre?
A: No. This is a multi-mode SR4 optic. Single-mode links require a different 40G transceiver type.

Q: What connector does it use?
A: It uses a 12-fibre MPO connector, so a matching MPO patch lead or breakout cable is needed.
