• White Fortinet FortiWiFi 40F FWF-40F-N security appliance with 5 GE RJ45 ports
1 1

Fortinet

Fortinet FWF-40F-N | FortiWiFi 40F Wireless Firewall, 5x GE, 802.11ac-W2

Fortinet FWF-40F-N | FortiWiFi 40F Wireless Firewall, 5x GE, 802.11ac-W2

Authorised Fortinet Partner

FWF-40F-N

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FortiWiFi 40F (FWF-40F-N) is a desktop next-generation firewall with an integrated dual-band 802.11ac Wave 2 wireless access point, built for small offices and branch sites that need security, SD-WAN and Wi-Fi in one appliance. It provides 5 x GE RJ45 ports (4 internal, 1 WAN) and delivers 5 Gbps of IPv4 firewall throughput, 1 Gbps of IPS throughput and 800 Mbps of NGFW throughput. This -N regional wireless variant belongs to the FWF-40F family and uses the 802.11ac-W2 radio with 3x3 MU-MIMO.

The fanless desktop design runs silently in open office environments, while FortiGuard security services support IPS, application control and SSL inspection. IPsec and SSL VPN are supported, and a FortiLink port allows the unit to manage FortiSwitch devices, making it a practical branch gateway for Fortinet Security Fabric deployments.

Features

- Integrated wireless access point with dual-band 802.11ac Wave 2
- FortiGuard security services support (IPS, application control, SSL inspection)
- SD-WAN capability and IPsec/SSL VPN
- FortiLink port for managing FortiSwitches
- Fanless, silent desktop design
- Compliance: FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 5 x GE RJ45 ports (4 x internal, 1 x WAN)
- Wireless: 802.11a/b/g/n/ac-W2, single radio (2.4GHz/5GHz), 3x3 MU-MIMO
- Max Wi-Fi speeds: 1300 Mbps @ 5GHz, 450 Mbps @ 2.4GHz
- Max Tx power 20 dBm; antenna gain 3.5 dBi @ 5GHz, 5 dBi @ 2.4GHz
- IPv4 Firewall Throughput: 5 / 5 / 5 Gbps (1518/512/64 byte UDP)
- IPS Throughput: 1 Gbps
- NGFW Throughput: 800 Mbps
- Threat Protection Throughput: 600 Mbps
- IPsec VPN Throughput (512 byte): 4.4 Gbps
- SSL-VPN Throughput: 490 Mbps; SSL Inspection Throughput: 310 Mbps
- Concurrent Sessions (TCP): 700,000; New Sessions/sec: 35,000
- Firewall latency 2.97 µs; 7.5 Mpps
- Virtual Domains: 10; max 8 FortiSwitches; max 16/8 FortiAPs
- 1 x USB port, 1 x RJ45 console port
- Dimensions 38.5 x 216 x 160 mm; weight 1 kg; desktop, fanless
- Power: 12Vdc 3A external adapter; max 16.6 W
- Operating temperature 0-40°C; humidity 10-90% non-condensing
- HA: Active-Active, Active-Passive, Clustering

FAQs

Q: Does the FortiWiFi 40F FWF-40F-N include built-in Wi-Fi?
A: Yes. It has an integrated dual-band 802.11ac Wave 2 radio (2.4GHz and 5GHz) with 3x3 MU-MIMO, delivering up to 1300 Mbps on 5GHz and 450 Mbps on 2.4GHz.

Q: How many network ports does it have?
A: It provides 5 x GE RJ45 ports, made up of 4 internal ports and 1 WAN port, plus a USB port and an RJ45 console port.

Q: What firewall and VPN performance can I expect?
A: IPv4 firewall throughput is 5 Gbps, IPS throughput is 1 Gbps, NGFW throughput is 800 Mbps and IPsec VPN throughput is 4.4 Gbps. SSL-VPN throughput is 490 Mbps.

Q: Can it manage FortiSwitch and FortiAP devices?
A: Yes. A FortiLink port lets it manage up to 8 FortiSwitches, and it supports management of up to 16/8 FortiAPs.

Q: Is the unit silent and suitable for desktop use?
A: Yes. It is a fanless desktop appliance measuring 38.5 x 216 x 160 mm and weighing 1 kg, powered by a 12Vdc 3A external adapter.

Q: What makes the -N model different from other FWF-40F variants?
A: The -N is a regional wireless variant within the FWF-40F family. It has the same 5 x GE RJ45 ports and 802.11ac-W2 Wi-Fi, with the regional suffix indicating the wireless region it is built for.
