Fortinet FWF-40F-3G4G-N | FortiWiFi 40F Wireless Firewall, 3G/4G/LTE, Wi-Fi 5, 5x GE

Fortinet FWF-40F-3G4G-N | FortiWiFi 40F Wireless Firewall, 3G/4G/LTE, Wi-Fi 5, 5x GE

Authorised Fortinet Partner

FWF-40F-3G4G-N

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FortiWiFi 40F-3G4G is a compact, fanless desktop wireless next-generation firewall and Secure SD-WAN appliance for branch offices and mid-sized businesses. It combines an embedded 3G/4G/LTE modem with dual Nano SIM slots, a built-in 802.11ac Wi-Fi 5 radio and 5 x GE RJ45 ports, so a single unit covers security, wired and wireless access and cellular WAN failover.

Performance is delivered by Fortinet's SoC acceleration, with 5 Gbps IPv4 firewall throughput, 800 Mbps NGFW throughput and 4.4 Gbps IPsec VPN throughput. The integrated wireless controller manages FortiAP units, FortiLink-enabled ports manage FortiSwitch, and FortiGuard security services provide IPS, application control, antivirus and web filtering.

Features

- Secure SD-WAN with next-generation firewall capabilities
- Fanless, compact desktop design
- FortiGuard security services support (IPS, application control, antivirus, web filtering)
- Hardware-accelerated performance via Fortinet SoC
- FortiLink-enabled ports for managing FortiSwitch
- Cellular WAN failover and backup via integrated 3G/4G/LTE modem with dual SIM
- Integrated wireless controller for FortiAP management

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 5 x GE RJ45 ports (1 x WAN, 4 x switch/LAN)
- Embedded 3G/4G/LTE cellular modem with 2 x Nano SIM slots
- Wireless: single radio, 2.4GHz/5GHz, 802.11a/b/g/n/ac-W2
- Antenna ports (SMA): 3 for Wi-Fi, 3 for WWAN cellular
- 1 x USB port, 1 x RJ45 console port
- IPv4 firewall throughput: 5 / 5 / 5 Gbps (1518 / 512 / 64 byte UDP)
- IPS throughput: 1 Gbps
- NGFW throughput: 800 Mbps
- Threat protection throughput: 600 Mbps
- SSL inspection throughput: 310 Mbps
- IPsec VPN throughput (512 byte): 4.4 Gbps
- SSL-VPN throughput: 490 Mbps
- Concurrent sessions (TCP): 700,000; new sessions per second: 35,000
- Gateway-to-gateway IPsec tunnels: 200; client-to-gateway: 250
- Virtual domains: 10
- Maximum FortiSwitches managed: 8
- High availability: Active-Active, Active-Passive, Clustering
- Dimensions: 40.5 x 216 x 160 mm; weight 1 kg; desktop form factor
- Power: external 12V DC 3A adapter (100-240V AC); maximum 19.8 W
- Operating temperature 0-40°C; humidity 10-90% non-condensing

FAQs

Q: Does the FortiWiFi 40F-3G4G include a built-in cellular modem?
A: Yes. It has an embedded 3G/4G/LTE modem with two Nano SIM slots and three SMA antenna ports for WWAN, which can be used for WAN failover or primary connectivity.

Q: What Wi-Fi standard does this firewall support?
A: It has a single radio operating on 2.4GHz and 5GHz, supporting 802.11a/b/g/n/ac-W2 (Wi-Fi 5), with three SMA antenna ports for Wi-Fi.

Q: What are the wired interfaces on the FWF-40F-3G4G-N?
A: It provides 5 x GE RJ45 ports, 1 x USB port and 1 x RJ45 console port.

Q: What throughput can I expect with security features enabled?
A: It delivers 800 Mbps NGFW throughput, 600 Mbps threat protection throughput and 1 Gbps IPS throughput, with 5 Gbps IPv4 firewall throughput.

Q: Can it manage FortiSwitch and FortiAP devices?
A: Yes. FortiLink-enabled ports allow management of up to 8 FortiSwitch units, and the integrated wireless controller manages FortiAP access points.

Q: How is the unit powered and mounted?
A: It is a fanless desktop unit powered by an external 12V DC 3A adapter (100-240V AC input), weighing 1 kg.
