Fortinet FN-TRAN-SFP+BD33 | 10G SFP+ BiDi Transceiver, 30km, TX 1331nm/RX 1271nm

Fortinet FN-TRAN-SFP+BD33 | 10G SFP+ BiDi Transceiver, 30km, TX 1331nm/RX 1271nm

Authorised Fortinet Partner

FN-TRAN-SFP+BD33

Stock Status: Enquire

$458.78 inc. GST
$417.07 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FN-TRAN-SFP+BD33 is a 10GE SFP+ BiDi transceiver for long-range single-mode fibre links up to 30km. It uses a single LC connector and transmits at 1331nm while receiving at 1271nm, so one strand of fibre carries both directions. This is the 1331nm transmit end of a BiDi pair and is matched with the FN-TRAN-SFP+BD27, which is ordered separately.

Designed for systems with SFP+ slots, the module operates across a temperature range of -5°C to 85°C. It suits campus backbone, inter-building and metro links where fibre strands are limited and a single-fibre 10G connection is needed.

Features

- Single-fibre bidirectional design reduces fibre strand requirements
- 30km reach over single-mode fibre for long-range 10G links
- Single LC connector for simple cabling
- Wide operating temperature range of -5°C to 85°C
- Matched wavelength pairing with the FN-TRAN-SFP+BD27 module

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 10GE SFP+ BiDi transceiver
- Long range 30km
- Single LC connector, single-mode fibre (SMF)
- TX 1331nm / RX 1271nm
- Operating temperature -5°C to 85°C
- For systems with SFP+ slots
- Pairs with FN-TRAN-SFP+BD27 (ordered separately)

FAQs

Q: What does the FN-TRAN-SFP+BD33 pair with?
A: It is designed to pair with the FN-TRAN-SFP+BD27 at the other end of the link. The BD27 is ordered separately.

Q: What wavelengths does this transceiver use?
A: It transmits at 1331nm and receives at 1271nm over a single strand of single-mode fibre.

Q: What is the maximum reach?
A: This module supports long-range links up to 30km over single-mode fibre.

Q: What connector does it use?
A: It uses a single LC connector, as BiDi technology carries both transmit and receive on one fibre.

Q: Can I connect two FN-TRAN-SFP+BD33 modules to each other?
A: No. BiDi optics work as a matched pair with opposite wavelengths, so this module needs to be paired with the FN-TRAN-SFP+BD27.

Q: What type of port does it fit?
A: It fits systems with SFP+ slots and provides a 10GE connection.
