• Fortinet logo with red grid O on FN-TRAN-SFP+BD27 10Gbps BIDI transceiver
1 1

Fortinet

Fortinet FN-TRAN-SFP+BD27 | 10G SFP+ BIDI Transceiver, 30km, Single-Mode, LC

Fortinet FN-TRAN-SFP+BD27 | 10G SFP+ BIDI Transceiver, 30km, Single-Mode, LC

Authorised Fortinet Partner

FN-TRAN-SFP+BD27

Stock Status: Enquire

$458.78 inc. GST
$417.07 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FN-TRAN-SFP+BD27 is a 10GE SFP+ BIDI transceiver module designed for long-range single-fibre links of up to 30km over single-mode fibre. It transmits at 1271nm and receives at 1331nm through a single LC connector, allowing a full 10 Gbps link over one strand of fibre instead of a fibre pair.

This module is intended for systems with SFP+ slots and must be paired with the FN-TRAN-SFP+BD33 at the far end of the link, which is ordered separately. With an operating temperature range of -5°C to 85°C, it suits campus backbones, inter-building links and other long-distance deployments where fibre strands are limited.

Features

- Single-fibre bidirectional transmission halves fibre strand usage
- Long-range 30km reach over single-mode fibre
- Extended operating temperature range of -5°C to 85°C
- Single LC connector for simple cabling
- Suited to systems with SFP+ slots

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: 10GE SFP+ BIDI transceiver module
- Reach: up to 30km
- Fibre type: single-mode fibre (SMF), single strand
- Connector: single LC
- Wavelength: TX 1271nm / RX 1331nm
- Operating temperature: -5°C to 85°C
- Compatible with systems with SFP+ slots
- Must be paired with FN-TRAN-SFP+BD33 at the far end (ordered separately)

FAQs

Q: What does the FN-TRAN-SFP+BD27 pair with?
A: It must be paired with the FN-TRAN-SFP+BD33 at the far end of the link. The BD33 is ordered separately.

Q: What is the maximum reach of this transceiver?
A: It supports links of up to 30km over single-mode fibre.

Q: Does it need a fibre pair?
A: No. As a BIDI module it transmits at 1271nm and receives at 1331nm over a single strand of single-mode fibre using a single LC connector.

Q: What type of port does it fit?
A: It is designed for systems with SFP+ slots and provides a 10GE link.

Q: What is the operating temperature range?
A: The module operates from -5°C to 85°C.
