Fortinet

Fortinet FN-TRAN-SFP-1BU40 | 1G SFP BiDi Transceiver, Single-Mode, 40km, TX 1310nm / RX 1490nm

Fortinet FN-TRAN-SFP-1BU40 | 1G SFP BiDi Transceiver, Single-Mode, 40km, TX 1310nm / RX 1490nm

Authorised Fortinet Partner

FN-TRAN-SFP-1BU40

Stock Status: Enquire

$357.48 inc. GST
$324.98 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FN-TRAN-SFP-1BU40 is a 1 GE SFP BiDi transceiver module for long-range single-mode fibre links up to 40km. It transmits at 1310nm and receives at 1490nm over a single LC fibre connection, which halves the number of fibre strands needed for a link compared with a standard duplex transceiver.

This module is one end of a matched BiDi pair and connects to the FN-TRAN-1BD40 at the opposite end, which is ordered separately. It suits systems with SFP slots and has an operating temperature range of -40°C to 85°C, making it suitable for demanding installations.

Features

- Bi-directional transmission over a single fibre strand
- Long-range 40km reach over single-mode fibre
- Wide operating temperature range of -40°C to 85°C
- For systems with SFP slots

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 1 GbE SFP BiDi transceiver
- Reach: 40km
- Single LC connector, single-mode fibre (SMF)
- TX 1310nm / RX 1490nm
- Operating temperature: -40°C to 85°C
- Pairs with FN-TRAN-1BD40 (ordered separately)

FAQs

Q: What does this transceiver connect to at the other end of the link?
A: It is designed to pair with the FN-TRAN-1BD40 BiDi module, which is ordered separately. A BiDi link requires matched modules with opposite transmit and receive wavelengths.

Q: What is the maximum reach of the FN-TRAN-SFP-1BU40?
A: It supports links up to 40km over single-mode fibre.

Q: Does it need one fibre or two?
A: It uses a single LC connector and a single fibre strand, transmitting at 1310nm and receiving at 1490nm.

Q: What fibre type is required?
A: Single-mode fibre (SMF) is required for this module.

Q: What speed does this module support?
A: It is a 1 GE SFP transceiver, suited to systems with SFP slots.

Q: What temperature range can it operate in?
A: The module operates from -40°C to 85°C.
