Fortinet FN-TRAN-SFP-1BD40 | 1G SFP BIDI Transceiver, 40km, TX1490/RX1310nm

Fortinet FN-TRAN-SFP-1BD40 | 1G SFP BIDI Transceiver, 40km, TX1490/RX1310nm

Authorised Fortinet Partner

FN-TRAN-SFP-1BD40

Stock Status: Enquire

$402.28 inc. GST
$365.71 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FN-TRAN-SFP-1BD40 is a 1 GE SFP BIDI transceiver module for long-distance single-fibre links up to 40km over single-mode fibre. It transmits at 1490nm and receives at 1310nm through a single LC connector, halving the fibre count needed for point-to-point campus, metro and inter-building runs.

This is the BD end of a matched pair and must be deployed with the complementary FN-TRAN-SFP-1BU40 at the far end, ordered separately. With an operating temperature range of -40°C to 85°C, it suits harsh and outdoor-cabinet environments, and it is designed for Fortinet systems with SFP and SFP+ slots.

Features

- Bidirectional operation over a single fibre strand
- Long-range 40km reach
- Extended temperature range suits harsh environments
- Single LC connector for simple cabling

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 1 GE SFP BIDI (1000Base-BX) transceiver
- Reach: 40km over single-mode fibre (SMF)
- Connector: single LC
- TX 1490nm / RX 1310nm
- Operating temperature: -40°C to 85°C
- For systems with SFP/SFP+ slots
- Pairs with FN-TRAN-SFP-1BU40 (ordered separately)

FAQs

Q: What is the FN-TRAN-SFP-1BD40 paired with?
A: It is the BD end of a BIDI pair and must connect to the complementary FN-TRAN-SFP-1BU40 transceiver at the far end. The 1BU40 is ordered separately.

Q: How far can this transceiver reach?
A: It supports links up to 40km over single-mode fibre.

Q: Does it need two fibre strands?
A: No. It is a bidirectional transceiver that transmits at 1490nm and receives at 1310nm over a single fibre strand with a single LC connector.

Q: Can I install it in a port with an SFP+ slot?
A: Yes. It is designed for systems with SFP or SFP+ slots and operates at 1 GE speed.

Q: Is it suitable for harsh environments?
A: Yes. It has an operating temperature range of -40°C to 85°C, which suits outdoor cabinets and industrial deployments.

Q: Can I use two FN-TRAN-SFP-1BD40 modules at both ends of a link?
A: No. Because the transmit and receive wavelengths are asymmetric, one end needs the BD module (TX 1490nm/RX 1310nm) and the other end needs the BU module, FN-TRAN-SFP-1BU40.
