Fortinet

Fortinet FG-81F-POE | Next-Gen Firewall, 10 Gbps, 8x GE PoE, 2x RJ45/SFP, 128GB SSD

Fortinet FG-81F-POE | Next-Gen Firewall, 10 Gbps, 8x GE PoE, 2x RJ45/SFP, 128GB SSD

Authorised Fortinet Partner

FG-81F-POE

Stock Status: Enquire

$3,202.04 inc. GST
$2,910.95 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FortiGate 81F-POE is a desktop next-generation firewall and secure SD-WAN appliance for small branch offices and distributed enterprise sites. It combines 8x GE RJ45 PoE ports, 2x RJ45/SFP shared media WAN ports and a 128GB SSD for local logging and storage, delivering up to 10 Gbps of firewall throughput on Fortinet's SoC4 security processor.

Built-in PoE+ with a 96W power budget lets you power access points, IP cameras and phones directly from the firewall, while FortiLink ports allow FortiSwitch management. It runs FortiOS as part of the Fortinet Security Fabric and supports FortiGuard security subscriptions and FortiCare support.

Features

- Secure SD-WAN with application-aware path steering
- Integrated next-generation firewall with IPS, application control, SSL inspection and threat protection
- Powered by FortiOS and part of the Fortinet Security Fabric
- SoC4 ASIC for accelerated security and networking performance
- Built-in PoE+ ports to power access points, cameras and phones
- FortiLink ports to manage FortiSwitches
- Manages FortiAP wireless access points
- Compatible with FortiGuard security subscriptions and FortiCare support
- HA clustering support

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 8 x GE RJ45 PoE/PoE+ ports (6 internal + 2 FortiLink), 96W PoE power budget, 30W max per port (802.3at)
- 2 x GE RJ45/SFP shared media WAN ports
- 1 x RJ45 console port, 1 x USB 3.0 Type A
- 128GB SSD onboard storage
- Firewall throughput: 10 / 10 / 7 Gbps (1518 / 512 / 64 byte UDP)
- Firewall latency: 3.23 µs (64 byte UDP)
- Firewall throughput: 10.5 Mpps
- IPS throughput: 1.4 Gbps
- NGFW throughput: 1 Gbps
- Threat protection throughput: 900 Mbps
- IPsec VPN throughput: 6.5 Gbps (512 byte)
- SSL inspection throughput: 715 Mbps (IPS, avg. HTTPS)
- SSL-VPN throughput: 950 Mbps
- Application control throughput: 1.8 Gbps
- Concurrent sessions (TCP): 1,500,000
- New sessions per second (TCP): 45,000
- Gateway-to-gateway IPsec VPN tunnels: 200
- Virtual domains: 10 / 10 (default / max)
- Managed FortiAPs: 96 total / 48 tunnel
- Managed FortiSwitches: 24
- High availability: Active-Active, Active-Passive, Clustering
- Hardware acceleration: Fortinet SoC4 secure SD-WAN ASIC
- Trusted Platform Module (TPM)
- Dimensions: 216 x 178 x 60 mm, weight approximately 1.4 kg
- Desktop, wall or rack mountable form factor

FAQs

Q: How many PoE ports does the FortiGate 81F-POE have?
A: It has 8 x GE RJ45 PoE/PoE+ ports (6 internal and 2 FortiLink) with a 96W total PoE budget and up to 30W per port (802.3at).

Q: What WAN connectivity options are available?
A: The unit provides 2 x GE RJ45/SFP shared media WAN ports, so each can use either copper RJ45 or an SFP module.

Q: Does this model include local storage?
A: Yes. It includes a 128GB SSD for local logging and storage, which distinguishes it from variants without onboard storage.

Q: What firewall throughput can I expect?
A: Firewall throughput is 10 Gbps (1518 and 512 byte UDP) and 7 Gbps (64 byte UDP), with 1 Gbps NGFW throughput and 900 Mbps threat protection throughput.

Q: Can it manage FortiSwitch and FortiAP devices?
A: Yes. It can manage up to 24 FortiSwitches via FortiLink and up to 96 FortiAPs (48 in tunnel mode).

Q: Does it support high availability?
A: Yes. It supports Active-Active, Active-Passive and clustering HA modes.
