Fortinet

Fortinet FBS-10F-WIFI-N | FortiSASE Branch Extension Device, Wi-Fi 6, 900Mbps IPsec, Region N

Fortinet FBS-10F-WIFI-N | FortiSASE Branch Extension Device, Wi-Fi 6, 900Mbps IPsec, Region N

Authorised Fortinet Partner

FBS-10F-WIFI-N

Stock Status: Enquire

$680.58 inc. GST
$618.71 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FortiBranchSASE-10F-WiFi is a compact FortiSASE branch extension device designed to deliver rapid, cloud-managed connectivity and security to small branch offices, home offices, and temporary sites. Acting as a thin-edge appliance, it establishes an L2 VxLAN tunnel over IPsec back to FortiSASE, making branch hosts appear as internal LAN segments — all managed centrally without on-site firewall configuration. Key capabilities include integrated Wi-Fi 6 (802.11ax 2x2 dual-band), hardware-accelerated 900 Mbps IPsec throughput, and a PoE-capable LAN port, all in an indoor desktop/wall-mount form factor with wall mount kit included.

Deployed as part of the Fortinet Security Fabric, the FBS-10F-WiFi-N (Region Code N) supports both wired and wireless user connectivity and integrates with FortiSASE, remote FortiGate, FortiGate VM, or FortiGate-as-a-Service for centralised SSID configuration and IPAM. It is ideal for microbranch LAN deployments where full on-site hardware is impractical. FortiSASE Subscription Bundles (1-, 3-, or 5-year SASE Protection) are available separately.

Features

- FortiSASE managed thin-edge extension — security delivered from FortiSASE cloud via L2 VxLAN over IPsec tunnel
- Branch hosts appear as FortiGate internal LAN segments — no on-site firewall configuration required
- Integrated Wi-Fi 6 (802.11ax) dual-band radio for wireless branch user connectivity
- Hardware-accelerated IPsec throughput up to 900 Mbps for high-performance VPN tunnels
- PoE 802.3af/at LAN port for powering connected devices
- Centralized SSID configuration and IPAM managed by FortiSASE
- Compatible with FortiSASE, FortiGate (hardware/VM), and FortiGate-as-a-Service management
- Part of the Fortinet Security Fabric — supports comprehensive microbranch, home office, and temporary office deployments
- Compact indoor desktop/wall-mount design with included wall mount kit
- BLE (Bluetooth Low Energy) support for IoT and asset tracking use cases
- FortiSASE Subscription Bundles available (1-year, 3-year, 5-year SASE Protection)

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Wi-Fi: Integrated 2x2 2.4G/5G Wi-Fi 6 (802.11ax), 2x internal antennas
- WAN Port: 1x GbE RJ45
- LAN Port: 1x GbE RJ45
- PoE Port: 1x GbE RJ45 LAN/PoE (802.3af/at)
- USB: 1x USB 3.0 Type-A (5V/0.5A GPIO power)
- Console: 1x RJ45
- Bluetooth: 1x BLE (Bluetooth Low Energy)
- IPsec Throughput: 900 Mbps (hardware-accelerated)
- Power: Optional 12V DC / 3A adapter
- Form Factor: Indoor desktop / wall mount
- Wall Mount Kit: Included
- Region Code: N

FAQs

Q: What is the FortiBranchSASE-10F-WiFi and how does it differ from a traditional branch firewall?
A: The FortiBranchSASE-10F-WiFi is a thin-edge extension device, not a standalone firewall. It connects to FortiSASE via an L2 VxLAN over IPsec tunnel, offloading all security policy enforcement to the cloud. This eliminates the need for a full on-site firewall appliance at small branches, simplifying deployment and reducing hardware costs while maintaining enterprise-grade protection.

Q: Does this device require a FortiSASE subscription to operate?
A: Yes. The FBS-10F-WiFi requires a FortiSASE subscription (or compatible FortiGate/FortiGate VM management) to function, as security and SSID configuration are delivered centrally from FortiSASE. Separate 1-year, 3-year, and 5-year SASE Protection Bundle subscriptions are available — contact IP Trading for bundle pricing.

Q: What does 'Region Code N' mean for this SKU?
A: Region Code N refers to the specific regulatory Wi-Fi radio configuration for this unit's intended market. It is important to select the correct region code to ensure compliance with local wireless regulations in your deployment country.

Q: Can the FBS-10F-WiFi support both wired and wireless branch users simultaneously?
A: Yes. The device provides wired connectivity via its GbE LAN ports (including one PoE 802.3af/at port for powering a connected device) and wireless connectivity via its integrated Wi-Fi 6 dual-band radio, supporting mixed wired/wireless microbranch LAN environments.

Q: Can I purchase the FortiBranchSASE-10F-WiFi-N in Australia through IP Trading?
A: Yes. IP Trading (iptrading.com.au) is an Australian B2B IT hardware reseller supplying authentic Fortinet hardware including the FBS-10F-WIFI-N. Orders can be placed online or via the sales team for volume or project pricing.

Q: What management platforms are compatible with this device?
A: The FBS-10F-WiFi is compatible with FortiSASE cloud management, remote FortiGate (hardware or VM), FortiGate VM, and FortiGate-as-a-Service. It is part of the Fortinet Security Fabric ecosystem and can be centrally provisioned and monitored from any of these platforms.
