ATEN OL2000HV-AT-G | Professional Online Rack/Tower UPS, 2000VA/2000W, 8x C13

Name: ATEN OL2000HV-AT-G | Professional Online Rack/Tower UPS, 2000VA/2000W, 8x C13
Brand: ATEN
SKU: OL2000HV-AT-G
Price: 2030.33 AUD
Availability: BackOrder

Authorised ATEN Partner

SKU:OL2000HV-AT-G

Stock Status: Enquire

$2,030.33 inc. GST

$1,845.75 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The ATEN OL2000HV-AT-G is a 2U rack/tower double-conversion online UPS rated 2000VA/2000W for 220/230/240V mains, supplied for the AU/UK region. It provides true online protection with a power factor of 1, eight battery and surge protected IEC C13 outlets and a hot-swappable battery pack, making it suited to server racks, network cabinets and critical equipment rooms.

USB (HID) and RS-232 ports provide local monitoring, and an optional SNMP card (SP100) adds network management alongside either port. An EPO connector, a multi-function LCD, programmable power management outlets and an ECO mode with efficiency above 96% give administrators the control needed for dependable day-to-day operation. Runtime can be extended with the BP48V18AH extended battery module.

Features

- True double-conversion online protection with output power factor of 1
- Output voltage regulation within 1%
- ECO mode with up to 97% efficiency
- Hot-swappable battery design for easy replacement
- Programmable power management outlets to extend battery time for critical devices
- Emergency Power Off (EPO) connector on the rear panel
- USB or RS-232 can run alongside the optional SNMP card at the same time
- Multi-function LCD showing input voltage, battery capacity, power, status and estimated runtime
- Over-voltage cut-off protection and MOV surge immunity
- Smart battery charger adjusts charging voltage to temperature to extend battery life
- Cold start capability
- Rack or tower deployment in a 2U chassis

Warranty

ATEN products sold by IP Trading are backed by a 24-month warranty against material defects and faulty workmanship from the date of shipment. Included accessories such as adapters and cables are covered for the same 24-month period, while batteries are covered by a 12-month warranty.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- 2000VA / 2000W, power factor 1
- True online double-conversion topology
- Input: 220/230/240 VAC, IEC 320 C20, 160-300 VAC at 100% load
- Input frequency range: 40-70 Hz
- 8 x IEC 320 C13 outlets, all battery and surge protected
- Pure sine wave output on battery, 50/60 Hz
- Transfer time: 0 ms (AC to battery), 4 ms (inverter to bypass, ECO)
- Runtime: 9.56 min at half load, 3.19 min at full load
- Battery: 4 x 12V/9Ah sealed lead-acid (48V), hot-swappable
- Typical recharge time: 3 hours to 95% capacity
- Ports: USB (HID), RS-232, EPO connector, optional SNMP card (SP100)
- 2U rack/tower, 8.8 x 43.8 x 51.0 cm, 20.7 kg
- Operating temperature: 0-40 degrees C
- Audible noise: less than 50 dB at 1 m
- Certifications: CE, RoHS
- Includes rack mounting kit, rail slide kit, tower stand set, RS-232 and USB cables and power cords

FAQs

Q: Is the OL2000HV-AT-G a true online UPS?
A: Yes. It uses double-conversion topology, so connected equipment is always powered from the inverter with 0 ms transfer time to battery.

Q: How many outlets does it have and what type?
A: It has eight IEC 320 C13 outlets, all of which are battery and surge protected. The input is an IEC 320 C20 inlet.

Q: Can I add network monitoring?
A: Yes. An optional SNMP card (SP100) adds network management, and USB or RS-232 can be used at the same time. USB (HID) and RS-232 ports are built in for local monitoring.

Q: Can the runtime be extended?
A: Yes. The BP48V18AH extended battery module can be added to increase runtime, and the BC48V9AH is the replacement battery pack.

Q: Can it be rack mounted or used as a tower?
A: Both. It is a 2U rack/tower unit and ships with a rack mounting kit, rail slide kit and tower stand set.

Q: What is the mains voltage and what power cords are included?
A: It operates on 220/230/240 VAC. The box includes four IEC C19 power cables (C19/C20, C19/Schuko, C19/UK and C19/AU 15A).

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .
