Arista QDD-800G-2FR4 | 800G QSFP-DD Transceiver, 2x 400GBASE-FR4, 2km

Authorised Arista Partner

SKU:QDD-800G-2FR4

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The QDD-800G-2FR4 is an 800G QSFP-DD optical transceiver that operates as two independent 400GBASE-FR4 links in a single module. It uses two duplex LC connectors and reaches up to 2km over duplex G.652 single-mode fibre, making it well suited to 800G to 2x 400G breakout deployments in data centre and campus spine environments.

Each 400G channel interoperates with standard 400GBASE-FR4 optics, using wavelengths of 1271, 1291, 1311 and 1331 nm. The module has a maximum power consumption of 16W and an operating case temperature range of 0 to 70 C. It is available in QSFP-DD Type 1 and Type 2 mechanical forms.

Features

- Interoperates with 2x 400GBASE-FR4 optics
- Two independent 400G FR4 channels in one QSFP-DD module
- Duplex LC connectivity over standard single-mode fibre
- Supports 800G to 2x 400G breakout use cases

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP-DD
- PHY type: 800GBASE-2FR4 (2x 400GBASE-FR4)
- Connectors: 2x duplex LC
- Fibre type: single-mode fibre (G.652)
- Maximum reach: 2km
- Wavelengths: 1271, 1291, 1311, 1331 nm
- Tx power: -3.3 to +3.5 dBm per lane
- Rx power: -7.3 to +3.5 dBm per lane
- Maximum power consumption: 16W
- Dimensions (H x W x L), Type 1: 13.5 x 18.4 x 78.3 mm
- Dimensions (H x W x L), Type 2: 13.5 x 18.4 x 93.3 mm
- Operating case temperature: 0 to 70 C
- Storage temperature: -40 to 70 C
- Relative humidity: 5 to 95%
- Operating altitude: 0-10,000 ft

FAQs

Q: What is the maximum reach of the QDD-800G-2FR4?
A: It reaches up to 2km over duplex G.652 single-mode fibre.

Q: What connectors does this transceiver use?
A: It uses two duplex LC connectors, one for each 400GBASE-FR4 channel.

Q: Can it be used for 800G to 2x 400G breakout?
A: Yes. The module presents two independent 400GBASE-FR4 links and interoperates with 400GBASE-FR4 optics, supporting 800G to 2x 400G breakout use cases.

Q: What fibre type is required?
A: Single-mode fibre (G.652) is required. The module is not designed for multimode fibre.

Q: What is the power consumption?
A: Maximum power consumption is 16W per module, which should be considered when planning port power and cooling.

Q: What operating temperature range is supported?
A: The operating case temperature range is 0 to 70 C, with a storage temperature range of -40 to 70 C.
