Arista DCS-7808R3-BND-DC | 7800R3 8-Slot Modular Chassis Switch, DC, 8x3kW PSU
Arista DCS-7808R3-BND-DC | 7800R3 8-Slot Modular Chassis Switch, DC, 8x3kW PSU
Authorised Arista Partner
SKU:DCS-7808R3-BND-DC
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7808R3-BND-DC is a 7800R3 Series 8-slot modular chassis switch bundle in a DC power configuration, built for data centre and cloud-grade routing deployments. The bundle combines the 16 RU 7808 chassis with eight 3kW D2 DC power supplies, six FM-R3 fabric modules and one 7800-Sup1A supervisor module, supplied with an extended rack kit. The fully scheduled, lossless architecture delivers up to 230 Tbps of fabric capacity (460 Tbps FDX) and up to 48 Bpps, with support for up to 288 x 400G ports once line cards are added.
The chassis provides 8 line card slots and 2 supervisor slots, with 100G, 200G and 400G operation and 800G readiness. It runs Arista EOS, a modular Linux-based network operating system, and supports secure Internet peering, MACsec, IPsec and VXLAN security. Line cards are sold separately, so the system can be sized to the port density and interface types a given network requires.
Features
Features
- Fully scheduled lossless architecture with cell-spraying fabric and per-port virtual output queuing
- Dual-input grid-redundant, hot-swappable power supplies with configurable redundancy up to N+N
- 1+1 supervisor redundancy and active-active fabric module redundancy
- Front-to-rear airflow
- 100G, 200G and 400G modes, 800G ready, with 400G ZR/ZR+ support
- Cloud-grade routing including secure Internet peering, MACsec, IPsec and VXLAN security
- Runs Arista EOS, a modular, Linux-based network operating system
- Typical power of 16W per 100G port and 25W per 400G port
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Bundle contents: 7808 chassis, 8x 3kW D2 DC power supplies, 6x FM-R3 fabric modules, 1x 7800-Sup1A supervisor, extended rack kit
- Form factor: 16 RU, 8-slot modular chassis
- Slots: 8 line card, 2 supervisor, 6 fabric module, 12 power supply (36 kW maximum power budget)
- Fabric capacity: up to 230 Tbps (460 Tbps FDX), up to 48 Bpps
- Port density: up to 288x 400G, 1152x 100G or 2304x 50G (line cards sold separately)
- Latency: under 4 microseconds (64 bytes)
- Packet buffer: up to 24 GB per line card
- Supervisor: multi-core x86 CPU with 64GB DRAM, optional SSD
- DC power input options: -40 to -72V or 240 to 380V DC
- Maximum power consumption: 19,698 W
- Airflow: front-to-rear, 1057.1 cfm typical, 2358 cfm maximum
- Dimensions (H x W x D): 70.3 x 44.1 x 94 cm (27.7 x 17.4 x 37.0 in)
- Weight: 101 kg chassis only, 325 kg full system
- Operating temperature: 0 to 40 C (32 to 104 F)
- Relative humidity: 5 to 90%
- Operating altitude: up to 3,000 m (10,000 ft)
FAQs
Q: What is included in the DCS-7808R3-BND-DC bundle?
A: The bundle includes the 7808 8-slot chassis, eight 3kW D2 DC power supplies, six FM-R3 fabric modules, one 7800-Sup1A supervisor module and an extended rack kit.
Q: Are line cards included?
A: No. Line cards are sold separately, so you can select the port speeds and interface types that suit your deployment. The chassis has 8 line card slots and supports up to 288x 400G ports.
Q: What DC input voltages does this bundle support?
A: The DC power input options are -40 to -72V DC or 240 to 380V DC.
Q: What redundancy does the chassis provide?
A: It supports 1+1 supervisor redundancy, active-active fabric module redundancy, and dual-input grid-redundant hot-swappable power supplies with configurable redundancy up to N+N.
Q: How much rack space does the 7808R3 chassis need?
A: The chassis occupies 16 RU and measures 70.3 x 44.1 x 94 cm (H x W x D). A fully loaded system weighs about 325 kg, so plan rack and floor loading accordingly.
Q: Which operating system does it run?
A: It runs Arista EOS, a modular, Linux-based network operating system.
