Arista DCS-7516N-CH | 7500R 16-Slot Modular Chassis Switch, Empty, 29RU

Arista DCS-7516N-CH | 7500R 16-Slot Modular Chassis Switch, Empty, 29RU

Authorised Arista Partner

SKU:DCS-7516N-CH

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

End of life
This product is end of life. Contact us for alternatives.

Description

The Arista DCS-7516N-CH is an empty 29RU modular chassis switch for the 7500R Series data centre switching platform. It provides 16 line card slots, 2 supervisor slots and 6 fabric module slots, scaling to as many as 576 x 100GbE ports or 2,304 x 10GbE/25GbE ports with up to 150 Tbps and 69 Bpps of throughput. Supplied as a chassis only with an AC or DC power option, it is built for large data centre spine and core deployments.

Line cards, supervisor modules, fabric modules and power supplies are ordered separately, so the system can be sized to the port density and speeds you need. The chassis supports 7500R and 7500R2 series wire-speed line cards and uses a distributed virtual output queue architecture with a lossless fabric, avoiding head-of-line blocking. It runs Arista EOS and uses front-to-rear airflow suited to data centre racks.

Features

- Distributed virtual output queue architecture with a lossless fabric that avoids head-of-line blocking
- Supports 7500R and 7500R2 series wire-speed line cards
- AC or DC power options, with power supplies ordered separately
- Front-to-rear airflow optimised for data centre deployments
- Common system architecture for long-term investment protection
- Runs Arista EOS

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Model: DCS-7516N-CH, chassis only
- 16 line card slots
- 2 supervisor slots (supports DCS-7516-SUP2)
- 6 fabric module slots (DCS-7516R-FM, 5+1 redundancy)
- 20 power supply slots
- Up to 576 x 100GbE, 576 x 40GbE, 1,152 x 50GbE or 2,304 x 10GbE/25GbE ports
- Up to 150 Tbps / 69 Bpps throughput
- 29RU, 50.3 x 19 x 37.1 in (128.9 x 48.3 x 94.1 cm)
- Weight: 295 lbs (134 kg) chassis only, 1025 lbs (465 kg) full system
- Maximum power consumption: 22,000 W
- Operating temperature: 0 to 40 C (32 to 104 F)
- Relative humidity: 5 to 90%
- Operating altitude: 0 to 3,000 m (10,000 ft)
- Certifications: BSMI, CE, KCC, NRTL, RCM (AU/NZ), UKCA, VCCI
- Compliance: FCC Class A, ICES-003, EN 55032, EN 62368-1, RoHS, WEEE

FAQs

Q: Does the DCS-7516N-CH include line cards, supervisors or power supplies?
A: No. It is an empty chassis only. Line cards, supervisor modules, fabric modules and power supplies are ordered separately.

Q: How many modules does this chassis support?
A: It provides 16 line card slots, 2 supervisor slots, 6 fabric module slots and 20 power supply slots.

Q: Which fabric and supervisor modules are compatible?
A: The chassis uses the DCS-7516R-FM fabric module with 5+1 redundancy and supports the DCS-7516-SUP2 supervisor module.

Q: What port densities can this chassis reach?
A: Depending on the line cards installed, it scales to as many as 576 x 100GbE ports or 2,304 x 10GbE/25GbE ports, with up to 150 Tbps and 69 Bpps of throughput.

Q: Can it be powered by AC or DC?
A: Yes. AC and DC power options are available, selected through the power supplies, which are ordered separately.

Q: What are the rack space and airflow requirements?
A: The chassis occupies 29RU and uses front-to-rear airflow. A fully populated system weighs up to 1025 lbs (465 kg), so plan rack and floor loading accordingly.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
