Arista

Arista DCS-7280TRA-48C6M-R | 7280R 48-Port 10G RJ45 Switch, 6x 100G QSFP, 2x AC, SSD

Arista DCS-7280TRA-48C6M-R | 7280R 48-Port 10G RJ45 Switch, 6x 100G QSFP, 2x AC, SSD

Authorised Arista Partner

SKU:DCS-7280TRA-48C6M-R

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista 7280R Series 48-port 10GBASE-T data centre switch router delivers 48 x 100M/1G/10G RJ45 ports and 6 x 100GbE QSFP100 uplinks in a 1RU chassis. Built on deep packet buffers with AlgoMatch support for scalable ACLs and policy-based forwarding, it suits high-density top-of-rack and leaf deployments that need wire-speed copper 10G access. This M variant includes expanded system memory and an SSD, with rear-to-front airflow and two AC power supplies.

The QSFP100 uplinks can run as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE, giving flexible aggregation options. With 2.16 Tbps full-duplex throughput, 720 Mpps forwarding and Arista EOS, it supports VXLAN, MLAG, BGP/OSPF/IS-IS routing, CloudVision management and Zero Touch Provisioning. Hot-swap redundant power supplies and fans keep the platform resilient in production environments.

Features

- AlgoMatch for scalable IPv4/IPv6 ACLs, policy-based forwarding and telemetry
- Deep packet buffers with VOQ architecture to eliminate head-of-line blocking
- 768K MAC addresses and 768K IPv4/IPv6 host routes, with up to 128-way ECMP
- VXLAN bridging and routing, VM Tracer integration
- LANZ microburst detection, DANZ advanced mirroring and TAP aggregation, IEEE 1588 PTP, sFlow
- Arista EOS with Zero Touch Provisioning, CloudVision, Advanced Event Management and eAPI/OpenConfig programmability
- MLAG, BGP/OSPF/IS-IS/RIPv2 routing, VRF, PBR, PIM multicast
- Hot-swap redundant power supplies and fans
- Expanded system memory and SSD for logging and data capture

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 48 x 10GBASE-T RJ45 ports (100Mb/1G/10G)
- 6 x QSFP100 uplink ports (6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE modes)
- 2.16 Tbps full-duplex throughput
- 720 Mpps packet forwarding rate
- 4 GB packet buffer memory
- Latency from 3.8 us
- Quad-core x86 CPU, expanded system memory (M variant)
- SSD storage included
- 2 USB ports, 1 x 100/1000 management port, 1 x RS-232 serial (RJ-45)
- 1RU, rear-to-front airflow, 2 x 500W AC hot-swap PSUs (1+1), 4 hot-swap fans (N+1)
- Typical power draw 290 W, maximum 405 W
- Dimensions 48.3 x 4.4 x 40.6 cm, weight 10.1 kg
- 10GBASE-T reach up to 30 m over Cat6a
- Operating temperature 0 to 40 C

FAQs

Q: What uplink speeds do the QSFP100 ports support?
A: The 6 QSFP100 ports can operate as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE, depending on the optics or breakout cabling used.

Q: What cabling is needed for the 10GBASE-T ports?
A: The RJ45 ports support 100Mb, 1G and 10G speeds, with 10GBASE-T reach up to 30 m over Cat6a cabling.

Q: How does this SKU differ from standard 7280RA models?
A: This M variant adds expanded system memory and an SSD, and ships with rear-to-front airflow and two AC power supplies.

Q: Is the power supply redundant?
A: Yes. It has two 500W AC hot-swap power supplies in a 1+1 configuration, plus four hot-swap fans in N+1 redundancy.

Q: What operating system does it run?
A: It runs Arista EOS, with a minimum EOS version of 4.19.0, and supports CloudVision, Zero Touch Provisioning and eAPI/OpenConfig programmability.

Q: Does it support AlgoMatch?
A: Yes. AlgoMatch is supported for scaling IPv4/IPv6 ACLs and policy-based forwarding.
