Arista DCS-7280TRA-48C6M-F | 7280RA 48x10GbE RJ45 6x100G QSFP Switch, SSD, 2x AC

Arista DCS-7280TRA-48C6M-F | 7280RA 48x10GbE RJ45 6x100G QSFP Switch, SSD, 2x AC

Authorised Arista Partner

SKU:DCS-7280TRA-48C6M-F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7280TRA-48C6M-F is a 1RU 7280RA data centre switch router with 48 wire-speed 100M/1G/10G BASE-T RJ45 ports and six 100GbE QSFP uplink ports. This expanded memory variant includes an SSD, AlgoMatch technology, front-to-rear airflow and dual AC power supplies, making it a strong fit for deep-buffer leaf and aggregation roles where large-scale routing and ACL tables are required.

Delivering 2.16 Tbps of throughput and 720 Mpps of forwarding with latency from 3.8 us, the switch runs Arista EOS. The QSFP ports support 100G, 50G, 40G, 25G and 10G breakout modes, giving flexible uplink and density options. The extensible platform supports bash, python and C++ for automation and custom tooling.

Features

- AlgoMatch technology for large-scale algorithmic ACL, route and flow-table matching
- Deep-buffer, wire-speed L2 and L3 forwarding
- Runs Arista EOS with a single binary image across platforms
- Extensible platform supporting bash, python and C++
- Flexible QSFP breakout modes for mixed-speed uplinks
- Dual AC power supplies for power redundancy

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 48 x 100M/1G/10G RJ45 (10GBASE-T) ports
- 6 x 100GbE QSFP ports with 100G, 50G, 40G, 25G and 10G breakout modes
- Throughput: 2.16 Tbps
- Packet forwarding: 720 Mpps
- Latency: from 3.8 us
- Packet buffer memory: 4GB
- Expanded system memory variant with SSD storage
- Front-to-rear airflow
- 2 x AC power supplies with C13-C14 cords
- 1RU form factor, 48.3 x 4.4 x 40.6 cm, 10.1 kg
- Typical/max power: 290 W / 405 W
- Max port counts: 6x100GbE, 12x50GbE, 6x40GbE, 24x25GbE, 72x10GbE

FAQs

Q: What ports does the DCS-7280TRA-48C6M-F provide?
A: It provides 48 x 100M/1G/10G BASE-T RJ45 ports and 6 x 100GbE QSFP ports. The QSFP ports support 100G, 50G, 40G, 25G and 10G breakout modes.

Q: What does the -M in the part number mean?
A: This variant has expanded system memory and includes an SSD, alongside front-to-rear airflow and 2 x AC power supplies.

Q: What is AlgoMatch?
A: AlgoMatch is Arista technology for large-scale algorithmic matching of ACLs, routes and flow tables on 7280RA models.

Q: What is the airflow direction and power configuration?
A: It uses front-to-rear airflow with 2 x AC power supplies supplied with C13-C14 cords. Typical power draw is 290 W with a maximum of 405 W.

Q: What operating system does it run?
A: It runs Arista EOS, which uses a single binary image across Arista platforms and supports bash, python and C++ extensibility.

Q: What is the form factor?
A: It is a 1RU switch measuring 48.3 x 4.4 x 40.6 cm and weighing 10.1 kg.
