Arista DCS-7280TRA-48C6-R | 7280RA 48x10GbE RJ45 Switch Router, 6x100G QSFP, Rear-to-Front, 2x AC
Arista DCS-7280TRA-48C6-R | 7280RA 48x10GbE RJ45 Switch Router, 6x100G QSFP, Rear-to-Front, 2x AC
Authorised Arista Partner
SKU:DCS-7280TRA-48C6-R
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7280TRA-48C6-R is a 1RU fixed-configuration data centre switch router from the 7280R Series, with 48 wire-speed 1/10G BASE-T RJ45 ports and six 100GbE QSFP100 uplinks. It includes AlgoMatch technology, rear-to-front airflow and dual hot-swap AC power supplies, making it well suited to leaf, spine and data centre interconnect deployments that need deep buffering and high-density 10GBASE-T server connectivity.
The QSFP100 uplinks can be configured as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE, giving flexible migration paths as server and network speeds increase. The switch runs Arista EOS, a single binary image used across all Arista platforms, and features redundant 1+1 power supplies and N+1 fans for resilient operation.
Features
Features
- Runs Arista EOS, a single binary image across all Arista products
- Deep dynamic packet buffering and VOQ architecture for data centre, leaf/spine and DCI use
- Flexible support for 10GbE, 25GbE, 40GbE, 50GbE and 100GbE speeds
- Hot-swap redundant power supplies and fans
- Reversible airflow platform
- AlgoMatch technology for efficient table utilisation
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 48 x 1/10GbE RJ45 (100M/1G/10G BASE-T) ports
- 6 x 100GbE QSFP100 ports (configurable as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE)
- AlgoMatch (Arista algorithmic match technology)
- Rear-to-front airflow (-R), reversible airflow platform
- 1 RU, 19 x 1.75 x 16 in (48.3 x 4.4 x 40.6 cm), 10.1 kg
- 2 x hot-swap AC power supplies (1+1 redundant, PWR-500AC)
- 4 x hot-swap fans (N+1 redundant)
- Power draw 290 W typical / 405 W maximum
- 4 GB flash storage, SSD option
- 1 x 10/100/1000 management port, 1 x RJ-45 RS-232 serial console, USB ports
- Quad-core x86 CPU, 8 GB DRAM
- Switching capacity 2.16 Tbps, 720 Mpps forwarding
- Up to 768K MAC address table entries, 4 GB packet buffer
FAQs
Q: What does the -R in DCS-7280TRA-48C6-R mean?
A: The -R suffix indicates rear-to-front airflow, where air enters at the port-side rear and exits at the front, suited to racks with reversed hot and cold aisle orientation.
Q: What speeds do the 100G QSFP ports support?
A: The six QSFP100 ports can be configured as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE using breakout, depending on the optics or cables used.
Q: Are the 48 downlink ports SFP+ or copper?
A: They are RJ45 1/10G BASE-T copper ports supporting 100M, 1G and 10G speeds, so they connect directly to copper server NICs over twisted-pair cabling.
Q: Does this switch include redundant power?
A: Yes. It ships with two hot-swap AC power supplies in a 1+1 redundant configuration, plus four hot-swap fans in an N+1 arrangement.
Q: What operating system does it run?
A: It runs Arista EOS, the same single binary image used across Arista's switching platforms.
Q: How is this SKU different from other 7280R models?
A: This model combines 48 x 1/10G RJ45 ports with 6 x 100G QSFP uplinks, rear-to-front airflow and dual AC power supplies in a 1RU chassis.
