Arista DCS-7280TRA-48C6-F | 7280R 48-Port 10GbE RJ45 Switch, 6x 100G QSFP, AlgoMatch

Arista DCS-7280TRA-48C6-F | 7280R 48-Port 10GbE RJ45 Switch, 6x 100G QSFP, AlgoMatch

Authorised Arista Partner

SKU:DCS-7280TRA-48C6-F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The 7280R 48-Port 10GbE RJ45 data centre switch router delivers 48 wire-speed 100Mb/1G/10GBASE-T ports and six QSFP100 uplinks in a 1RU fixed-configuration chassis. With 2.16 Tbps of full-duplex throughput, 720 Mpps forwarding and a 4 GB deep-buffer VOQ architecture, it suits top-of-rack and leaf deployments that need dense copper access and high-speed uplinks. This variant includes AlgoMatch, front-to-rear airflow and 2x AC power supplies with standard memory (no expansion memory or SSD).

The QSFP100 ports support 10/25/40/50/100GbE modes, allowing flexible uplink and breakout designs. Running Arista EOS with a single binary image, it supports VXLAN bridging and routing, MLAG, VRF, 128-way ECMP and rich telemetry, including LANZ microburst detection and DANZ advanced mirroring. Hot-swap 1+1 redundant AC power supplies and N+1 redundant fans provide resilience in production racks.

Features

- Deep-buffer virtual output queue (VOQ) architecture eliminates head-of-line blocking
- AlgoMatch for scalable access control, policy-based forwarding and telemetry
- Flexible QSFP100 ports support 10/25/40/50/100GbE modes
- Arista EOS single binary image with Linux shell access and extensibility (bash, Python, C++, Go, OpenConfig)
- CloudVision, Zero Touch Provisioning and Advanced Event Management
- LANZ microburst detection and DANZ advanced mirroring and TAP aggregation
- VXLAN bridging and routing with MLAG, VRF and 128-way ECMP
- IEEE 1588 PTP precision timing
- BGP, OSPF, IS-IS, MP-BGP, PIM and VRRP routing support
- Hot-swappable redundant power supplies and fans

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 48 x 10GBASE-T RJ45 ports (100Mb/1G/10G)
- 6 x QSFP100 ports (6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE modes)
- 2.16 Tbps full-duplex throughput
- 720 Mpps packet forwarding
- 4 GB packet buffer
- Latency from 3.8 us
- 8 GB system memory (32 GB optional)
- Quad-core x86 CPU
- 4 GB flash storage, 2 USB ports
- 1 x 100/1000 management port, 1 x RS-232 serial port (RJ-45)
- 2 x hot-swap 500W AC power supplies (1+1 redundant)
- 4 x hot-swap fans (N+1), FAN-7000H-F, front-to-rear airflow
- Typical/maximum power draw: 290 W / 405 W
- 1RU, 19 x 1.75 x 16 in (48.3 x 4.4 x 40.6 cm), 10.1 kg
- 10GBASE-T reach up to 30 m over Cat6a
- Operating temperature 0 to 40 C
- Scale: 768K MAC, 768K IPv4 host routes, 768K IPv6 host routes, 24K ACL entries per forwarding engine
- EOS feature licence Group 2, minimum EOS 4.19.0

FAQs

Q: What airflow and power configuration does this model have?
A: This SKU uses front-to-rear airflow with FAN-7000H-F fan modules and ships with two hot-swap 500W AC power supplies in a 1+1 redundant arrangement.

Q: Does the switch support 25G and 40G as well as 100G on the QSFP ports?
A: Yes. The six QSFP100 ports operate as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE depending on the optics and breakout cables used.

Q: What speeds do the RJ45 ports support?
A: The 48 RJ45 ports support 100Mb, 1G and 10GBASE-T, with 10GBASE-T reach of up to 30 m over Cat6a cabling.

Q: What is AlgoMatch?
A: AlgoMatch is Arista's algorithmic matching technology that enables large-scale access control lists, policy-based forwarding and telemetry. It is supported on this model.

Q: Does this variant include an SSD or expanded memory?
A: No. This variant ships with standard 8 GB system memory and no SSD. A 32 GB memory option and an SSD option are available for the platform.

Q: What software does it run?
A: It runs Arista EOS with a single binary image, requiring a minimum of EOS 4.19.0 and the Group 2 feature licence tier.
