Arista DCS-7280SRA-48C6M-F | 7280R 48x10G SFP+ Switch Router, 6x100G, MACsec, SSD
Arista DCS-7280SRA-48C6M-F | 7280R 48x10G SFP+ Switch Router, 6x100G, MACsec, SSD
Authorised Arista Partner
SKU:DCS-7280SRA-48C6M-F
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7280SRA-48C6M-F is a 7280R Series data centre switch router with 48 x 10GbE SFP+ ports and 6 x 100GbE QSFP28 uplinks, built for high-density leaf, edge and data centre interconnect deployments. This variant adds IEEE 802.1AE MACsec wire-speed encryption on the 100GbE ports, front-to-back airflow, SSD storage and expandable memory, making it well suited to secure site-to-site links.
AlgoMatch technology delivers scalable ACL and lookup performance, while deep packet buffers and wire-speed L2 and L3 forwarding support demanding routing and data centre workloads. The switch runs Arista EOS and offers 2.16 Tbps of switching capacity and 720 Mpps forwarding rate.
Features
Features
- AlgoMatch technology for scalable ACL and lookup
- IEEE 802.1AE MACsec wire-speed encryption on 100GbE ports for secure DCI and site-to-site links
- Wire-speed L2 and L3 forwarding
- Deep buffers for data centre and routing use cases
- Expandable memory and SSD storage
- Arista EOS software
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 48 x 10GbE SFP+ ports
- 6 x 100GbE QSFP28 uplink ports
- Switching capacity: 2.16 Tbps
- Forwarding rate: 720 Mpps
- Packet buffer: 4GB
- MAC address table: 768,000 entries
- VLAN IDs: 4096
- Latency from 3.8us
- CPU: Quad-core x86
- Memory: 8GB DRAM (32GB optional), 4GB flash
- Front-to-back airflow
- Management: 1 x RS-232 serial console, 2 x USB, management port
- Operating system: Arista EOS
FAQs
Q: What port configuration does the DCS-7280SRA-48C6M-F offer?
A: It provides 48 x 10GbE SFP+ ports and 6 x 100GbE QSFP28 uplink ports in a fixed-configuration switch router.
Q: Does this switch support MACsec encryption?
A: Yes. It supports IEEE 802.1AE MACsec wire-speed encryption on the 100GbE ports, suitable for securing data centre interconnect and site-to-site links.
Q: What airflow direction does this model use?
A: The -F suffix indicates front-to-back airflow.
Q: What is AlgoMatch?
A: AlgoMatch is Arista's technology for scalable ACL and lookup performance, allowing large rule sets to be handled at wire speed.
Q: Which operating system does it run?
A: It runs Arista EOS, the same software used across Arista data centre switching platforms.
Q: Can the memory be expanded?
A: Yes. It ships with 8GB DRAM, which can be expanded to 32GB, along with 4GB flash and SSD storage.
