Arista

Arista DCS-7280CR3-32P4-M | 7280R3 32x100G QSFP, 4x400G OSFP Switch, Expanded Memory

Arista DCS-7280CR3-32P4-M | 7280R3 32x100G QSFP, 4x400G OSFP Switch, Expanded Memory

Authorised Arista Partner

SKU:DCS-7280CR3-32P4-M

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7280CR3-32P4-M is a 1RU 100G/400G data centre switch router from the 7280R3 Series, built for high-density leaf, spine and routing roles. It delivers 32 x QSFP100 ports and 4 x 400G OSFP ports with up to 4.8 Tbps of wire-speed performance and an 8GB packet buffer. This -M variant adds expanded memory for larger forwarding tables, and is supplied with configurable fans and power supplies.

The flexible 400G OSFP ports allow capacity expansion with both 100G and 400G optics, while the QSFP100 ports support 100GbE and 40G with breakout options. It runs Arista EOS and includes a 100/1000 management port and an RS-232 RJ-45 serial console port for out-of-band management.

Features

- Deep-buffer, high-density 100G/400G leaf and spine switch router
- Flexible 400G OSFP ports for capacity expansion with 100G and 400G optics
- Runs Arista EOS
- Suited to data centre and routing roles with large forwarding tables
- Expanded memory for scale

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 32 x QSFP100 ports (100GbE, also 40G, with breakout options)
- 4 x 400G OSFP ports
- Up to 4.8 Tbps wire-speed performance
- 8GB packet buffer
- Expanded memory (-M) variant
- Fans and power supplies configurable, ordered separately
- 1RU form factor, 48.3 x 4.4 x 55.8 cm, 12.3 kg
- 1 x 100/1000 management port
- 1 x RS-232 serial (RJ-45) console port

FAQs

Q: What ports does the DCS-7280CR3-32P4-M provide?
A: It provides 32 x QSFP100 ports supporting 100GbE and 40G with breakout options, plus 4 x 400G OSFP ports, along with a 100/1000 management port and an RS-232 RJ-45 console port.

Q: What does the -M suffix mean on this model?
A: The -M suffix denotes the expanded memory variant of the 7280CR3-32P4, suited to deployments needing larger forwarding tables.

Q: Are the fans and power supplies included?
A: Fans and power supplies are configurable and ordered separately, so you can select the airflow direction and power options to suit your rack.

Q: What operating system does it run?
A: It runs Arista EOS.

Q: What is the switching performance and buffer size?
A: The 7280CR3-32P4 series delivers up to 4.8 Tbps of wire-speed performance with an 8GB packet buffer.

Q: What rack space does it need?
A: It is a 1RU switch measuring 48.3 x 4.4 x 55.8 cm and weighing 12.3 kg.
