Arista

Arista DCS-7280CR3-32P4-F | 7280R3 32x100G QSFP, 4x400G OSFP Switch, Front-to-Rear Air, AC

Arista DCS-7280CR3-32P4-F | 7280R3 32x100G QSFP, 4x400G OSFP Switch, Front-to-Rear Air, AC

Authorised Arista Partner

SKU:DCS-7280CR3-32P4-F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7280CR3-32P4-F is a 1RU fixed-configuration data centre switch router from the 7280R3 family, delivering 32 x 100GbE QSFP100 ports and 4 x 400GbE OSFP ports. Built for leaf, spine and service-provider roles, it runs Arista EOS and combines wire-speed forwarding with deep VOQ buffering. This SKU ships with front-to-rear airflow fans and two AC power supplies.

Breakout options provide up to 48 x 100G, 96 x 50G or 96 x 25G/10G interfaces, so one platform can serve mixed-speed environments as you migrate towards 400G. The full routing feature set includes BGP, OSPF, IS-IS, MPLS, Segment Routing, EVPN and VXLAN, and redundant hot-swappable power supplies and fans support resilient deployments.

Features

- Wire-speed L2/L3 forwarding with deep VOQ buffering that avoids head-of-line blocking
- Full routing feature set: BGP, OSPF, IS-IS, MPLS, Segment Routing, EVPN and VXLAN
- Flexible port speeds from 1G/10G up to 400G
- Single Arista EOS binary image across all Arista products
- Redundant, hot-swappable power supplies and fans

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 32 x 100GbE QSFP100 ports (also support 40G and lower speeds)
- 4 x 400GbE OSFP ports (400G/200G/100G)
- Up to 48 x 100G, 96 x 50G, or 96 x 25G/10G interfaces via breakout
- Forwarding rate 2 Bpps
- Latency from 3.8 us
- Quad-core x86 CPU
- 8 GB system memory
- Management: 1 x 100/1000 management port, 1 x RJ-45 RS-232 console, 1 x USB
- Front-to-rear airflow (FAN-7011H-F fans)
- 2 x PWR-1011 AC power supplies included
- 1RU form factor, rack mount kit included
- Runs Arista EOS

FAQs

Q: What port configuration does the DCS-7280CR3-32P4-F offer?
A: It provides 32 x 100GbE QSFP100 ports and 4 x 400GbE OSFP ports in a 1RU chassis. The 100G ports also support 40G and lower speeds, and breakout options extend this to up to 96 x 25G/10G interfaces.

Q: What airflow direction does this model use?
A: This SKU uses front-to-rear airflow with FAN-7011H-F fans. Confirm the airflow direction matches your hot and cold aisle layout before ordering.

Q: Does it include power supplies?
A: Yes. Two PWR-1011 AC power supplies are included, and the power supplies and fans are hot-swappable for redundancy.

Q: What operating system does it run?
A: It runs Arista EOS, the same single binary image used across Arista products.

Q: What roles is this switch suited to?
A: It is built for data centre leaf and spine roles as well as service-provider deployments, supported by deep VOQ buffering and a full routing feature set including BGP, MPLS, Segment Routing, EVPN and VXLAN.

Q: Are optics included?
A: No. The QSFP100 and OSFP ports require compatible transceivers or cables, which are purchased separately.
