Arista DCS-7280CR3-32P4 | 7280CR3 32x100G QSFP, 4x400G OSFP Switch Router, Configurable Fans/PSU
Arista DCS-7280CR3-32P4 | 7280CR3 32x100G QSFP, 4x400G OSFP Switch Router, Configurable Fans/PSU
Authorised Arista Partner
SKU:DCS-7280CR3-32P4
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7280CR3-32P4 is a 1RU fixed-configuration data centre switch router from the 7280R3 Series, combining 32 x 100GbE QSFP100 ports with 4 x 400GbE OSFP ports. It is built for cloud-grade routing with deep packet buffers and large route scale, making it well suited to data centre spine, edge and peering roles. This SKU is ordered with configurable fans and power supplies, so you choose the airflow direction through the modules you select.
The QSFP100 ports support 10/25/40/50/100G operation, while the OSFP ports run at 400G, 200G or 100G line rates for flexible uplink design. The platform includes a quad-core x86 CPU, 8 GB of system memory and 8 GB of flash storage, and runs Arista EOS. Fan and PSU modules are hot-swappable and ordered separately.
Features
Features
- Cloud-grade routing with deep packet buffers
- OSFP 400G uplink ports that also support 200G and 100G
- FlexRoute scalable routing for large IPv4/IPv6 route tables
- Accelerated sFlow monitoring
- 1RU form factor with hot-swappable, modular fan and PSU design
- Airflow direction selected through the chosen fan and PSU modules
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 32 x 100GbE QSFP100 ports (10/25/40/50/100G capable)
- 4 x 400GbE OSFP ports (400G, 200G and 100G line rates)
- Quad-core x86 CPU
- 8 GB system memory
- 8 GB flash storage
- 1 x USB port
- 1 x 100/1000 management port
- 1 x RS-232 serial port (RJ-45)
- 1RU fixed-configuration form factor
- Configurable fans and power supplies (modules ordered separately)
- Runs Arista EOS
FAQs
Q: Does the DCS-7280CR3-32P4 include fans and power supplies?
A: This SKU is ordered with configurable fans and power supplies. The fan and PSU modules are ordered separately, and the airflow direction is determined by the modules you choose.
Q: What port types does this switch router provide?
A: It provides 32 x 100GbE QSFP100 ports, which support 10/25/40/50/100G operation, and 4 x 400GbE OSFP ports, which support 400G, 200G and 100G line rates.
Q: What operating system does it run?
A: It runs Arista EOS.
Q: What management interfaces are available?
A: It includes one 100/1000 management port, one RS-232 serial console port (RJ-45) and one USB port.
Q: What rack space does it need?
A: It is a 1RU fixed-configuration platform, so it occupies a single rack unit.
Q: Can the OSFP ports be used at lower speeds?
A: Yes. The 4 x OSFP ports support 400G, 200G and 100G line rates, which allows flexible uplink and breakout designs.
