Arista

Arista DCS-7280CR3-32D4-R | 7280R3 32x100G + 4x400G QSFP-DD Switch, Rear-to-Front, Dual AC

Arista DCS-7280CR3-32D4-R | 7280R3 32x100G + 4x400G QSFP-DD Switch, Rear-to-Front, Dual AC

Authorised Arista Partner

SKU:DCS-7280CR3-32D4-R

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7280CR3-32D4-R is a 1RU fixed-configuration data centre switch router from the 7280R3 Series, delivering 32 x 100G QSFP100 ports plus 4 x 400G QSFP-DD ports with deep buffers and wire-speed L2 and L3 forwarding. This variant ships with rear-to-front airflow, dual AC power supplies (PWR-1011) and 8GB system memory, making it well suited to data centre racks with rear-facing cold aisles and 1+1 power redundancy.

Running Arista EOS, the 7280CR3-32D4 combines a VOQ architecture, dynamic deep packet buffering and the FlexRoute engine for large IP route scale. It supports VXLAN bridging and routing, MLAG and breakout to up to 96 total interfaces, making it a strong fit for spine, leaf and edge routing roles in high-density 100G and 400G environments.

Features

- Runs the same Arista EOS software image across all Arista products
- Wire-speed L2 and L3 forwarding with VOQ architecture to eliminate head-of-line blocking
- Dynamic deep packet buffer
- FlexRoute engine for large IP route scale
- VXLAN bridging and routing, MLAG, 802.3ad LACP and 4096 VLANs
- Accelerated sFlow sampling at line rate
- Hot-swappable redundant power supplies and fans

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 32 x 100G QSFP100 ports + 4 x 400G QSFP-DD ports
- Up to 4 x 400G, 48 x 100G or 36 x 40G (QSFP+) ports; up to 96 total interfaces via breakout
- 4.8 Tbps throughput (9.6 Tbps full duplex)
- 2 Bpps packet forwarding rate
- Latency from 3.8 µs
- 8 GB packet buffer
- Quad-core x86 CPU; 8 GB system memory (64 GB optional)
- 8 GB flash storage; 120 GB SSD with 64 GB system memory option
- 1 x 100/1000 management port, 1 x USB port
- Dual hot-swap PSUs (PWR-1011 AC or DC), 1+1 redundancy; FAN-7011H fan tray
- Typical/max power draw 535 W / 851 W
- 1RU; approx. 43.99 x 4.37 x 55.8 cm (W x H x D)
- Weight approx. 12.27 kg
- Rear-to-front airflow
- Minimum EOS 4.22.2; EOS Feature License Group 4

FAQs

Q: What port configuration does the DCS-7280CR3-32D4-R offer?
A: It provides 32 x 100G QSFP100 ports and 4 x 400G QSFP-DD ports in a 1RU chassis, with breakout support for up to 96 total interfaces.

Q: What does the -R suffix mean on this model?
A: The -R suffix denotes rear-to-front airflow. This SKU also includes dual AC power supplies (PWR-1011).

Q: Does this switch support power supply redundancy?
A: Yes. It has dual hot-swappable power supplies in a 1+1 redundant configuration, along with a hot-swappable FAN-7011H fan tray.

Q: What software does it run and which EOS version is required?
A: It runs Arista EOS and requires a minimum of EOS 4.22.2, with EOS Feature License Group 4.

Q: Does it support VXLAN and MLAG?
A: Yes. It supports VXLAN bridging and routing, MLAG, 802.3ad LACP and 4096 VLANs.

Q: How much system memory and buffer does it have?
A: This SKU has 8 GB of system memory (64 GB optional on other configurations) and an 8 GB packet buffer.
