Arista

Arista DCS-7280CR3-32D4-F | 7280R3 Data Centre Switch, 32x100G QSFP100, 4x400G QSFP-DD

Arista DCS-7280CR3-32D4-F | 7280R3 Data Centre Switch, 32x100G QSFP100, 4x400G QSFP-DD

Authorised Arista Partner

SKU:DCS-7280CR3-32D4-F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7280CR3-32D4-F is a fixed-configuration 1RU data centre switch router from the 7280R3 series, built for cloud-grade routing, Internet peering and carrier edge deployments. It provides 32x 100G QSFP100 ports and 4x 400G QSFP-DD ports with front-to-rear airflow, delivering wire-speed L2 and L3 forwarding with deep packet buffers.

The QSFP-DD ports support speeds from 10G to 400G, and the platform scales to up to 96 interfaces using breakout, giving flexibility to mix 400G, 100G, 50G and 25/10G connectivity. Support for EVPN services, carrier core transport protocols and PTP/SyncE timing makes it suited to 5G, metro and service provider networks.

Features

- Wire-speed L2 and L3 forwarding
- Cloud-grade routing with secure Internet peering and carrier edge VPN services
- EVPN services for 5G/MEC, CIN and Metro
- Carrier core transport (LDP, RSVP-TE, SR-TE) with FRR and TI-LFA high availability
- Timing support (PTP and SyncE)
- QSFP-DD ports support 10G to 400G speeds
- Deep packet buffers for demanding routing workloads

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 32 x QSFP100 ports
- 4 x QSFP-DD 400G ports
- Up to 4 x 400G, 48 x 100G, 96 x 50G, or 96 x 25/10G ports (maximum 96 interfaces)
- Throughput: 4.8 Tbps (9.6 Tbps FDX)
- Forwarding rate: 2 Bpps
- Latency from 3.8 us
- 8 GB packet buffer memory
- Quad-core x86 CPU
- 8 GB system memory (64 GB optional)
- 120 GB SSD storage
- Front-to-rear airflow
- 1RU fixed-configuration form factor

FAQs

Q: What port configuration does the DCS-7280CR3-32D4-F offer?
A: It provides 32 x QSFP100 ports and 4 x QSFP-DD 400G ports. Using breakout, it supports up to 4 x 400G, 48 x 100G, 96 x 50G or 96 x 25/10G ports, with a maximum of 96 interfaces.

Q: What is the airflow direction on this model?
A: This SKU uses front-to-rear airflow. Confirm it matches your rack's hot and cold aisle layout before ordering.

Q: What switching performance does it deliver?
A: It delivers 4.8 Tbps of throughput (9.6 Tbps full duplex) and a forwarding rate of 2 Bpps, with latency from 3.8 us.

Q: What use cases is the 7280R3 suited to?
A: It is aimed at cloud-grade routing, secure Internet peering, carrier edge VPN services, and EVPN-based 5G, CIN and metro deployments.

Q: Does it support service provider transport and timing features?
A: Yes. It supports carrier core transport with LDP, RSVP-TE and SR-TE, FRR and TI-LFA for high availability, and PTP and SyncE timing.

Q: What speeds do the QSFP-DD ports support?
A: The QSFP-DD ports support speeds from 10G up to 400G, depending on the optic or cable used.
