Arista

Arista DCS-7280CR2K-30# | 7280R2 30x100GbE QSFP Switch Router, AlgoMatch-2

Arista DCS-7280CR2K-30# | 7280R2 30x100GbE QSFP Switch Router, AlgoMatch-2

Authorised Arista Partner

SKU:DCS-7280CR2K-30#

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7280CR2K-30# is a 1U 7280R2 data centre switch router with 30 QSFP100 ports, AlgoMatch-2 and expanded memory. It is built for deep-buffer, high-density 100GbE spine, leaf and edge or peering roles where large routing tables and ACL scale matter.

This variant supports 10GbE, 25GbE, 40GbE, 50GbE and 100GbE speeds, with breakout options for up to 120 x 10GbE or 25GbE ports. Fans and power supplies are configured separately, so you can choose the airflow direction and PSU options to suit your rack. It runs Arista EOS.

Features

- Deep-buffer, high-density 100G switch router for data centre spine, leaf and edge or peering roles
- Runs Arista EOS network operating system
- Large routing table and ACL capacity from expanded memory and AlgoMatch-2
- Supports 100G, 50G, 40G, 25G and 10G speeds for flexible migration
- Selectable fan and PSU options for airflow choice

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 30 x QSFP100 ports
- Port speeds: 10GbE, 25GbE, 40GbE, 50GbE and 100GbE (10/25/50GbE via breakout)
- Up to 120 x 10GbE or 25GbE ports via breakout with FC and RS FEC
- Wire-speed switching performance of about 6Tbps
- 16GB packet buffer
- AlgoMatch-2 and expanded memory
- 1U, half-depth form factor
- Fans and power supplies configured separately
- 1 x 1GbE management port

FAQs

Q: What port speeds does the DCS-7280CR2K-30# support?
A: The 30 QSFP100 ports support 10GbE, 25GbE, 40GbE, 50GbE and 100GbE, with 10GbE, 25GbE and 50GbE available through breakout.

Q: Are fans and power supplies included?
A: No. This '#' SKU is the variant where fans and power supplies are configured separately, so you select the airflow and PSU options you need.

Q: What does the K model add over standard 7280R2 switches?
A: The K model adds AlgoMatch-2 and expanded memory, which increase routing table and ACL scale.

Q: How many breakout ports can it provide?
A: Up to 120 x 10GbE or 25GbE ports with FC and RS FEC using breakout from the 30 QSFP100 ports.

Q: Which operating system does it run?
A: It runs Arista EOS.

Q: What roles is this switch suited to?
A: It suits data centre spine, leaf and edge or peering deployments that need deep buffers and high-density 100G connectivity.
