Arista DCS-7280CR2A-60-F | 7280R2A 60x 100GbE QSFP Switch, AlgoMatch, Front-to-Rear Airflow, Dual AC
Arista DCS-7280CR2A-60-F | 7280R2A 60x 100GbE QSFP Switch, AlgoMatch, Front-to-Rear Airflow, Dual AC
Authorised Arista Partner
SKU:DCS-7280CR2A-60-F
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7280CR2A-60-F is a 2RU 100GbE data centre switch router from the Arista 7280R2A family, built around 60 QSFP100 ports and deep packet buffers. It delivers 12 Tbps of wire-speed switching capacity with 24GB of buffer memory and latency from 3.8 us, making it well suited to spine, edge and peering roles. This SKU ships with front-to-rear airflow and dual AC power supplies.
Each QSFP100 port supports 100GbE, 40GbE, 25GbE or 10GbE modes, and breakout provides up to 240 x 10GbE or 25GbE ports. AlgoMatch accelerates large-scale ACL and forwarding-table lookups, and the switch runs Arista EOS with MPLS, SR-MPLS and BGP routing support in the 7280R family. Hot-swap redundant power supplies and fan trays support continuous operation.
Features
Features
- Wire-speed 100GbE density in a 2RU system
- Deep buffering (24GB) with VOQ architecture
- AlgoMatch for large-scale ACL and forwarding-table lookups
- Runs Arista EOS
- Hot-swappable redundant power supplies and fan trays
- Supports MPLS, SR-MPLS and BGP routing in the 7280R family
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 60 x QSFP100 ports, each supporting 100GbE, 40GbE, 25GbE or 10GbE modes
- Up to 240 x 10GbE or 25GbE ports using breakout, with FC and RS FEC
- 12 Tbps wire-speed switching capacity
- 24GB packet buffer memory
- Latency from 3.8 us
- Quad-core x86 CPU
- AlgoMatch for large-scale ACL and forwarding-table lookups
- Front-to-rear airflow
- 1+1 redundant hot-swap AC power supplies
- N+1 hot-swap fan trays
- Typical/maximum power draw of 1760W / 1900W
- 2RU rack form factor
FAQs
Q: How many 100GbE ports does the DCS-7280CR2A-60-F provide?
A: It provides 60 QSFP100 ports, each of which can operate in 100GbE, 40GbE, 25GbE or 10GbE modes.
Q: Can this switch break out to 10GbE or 25GbE?
A: Yes. Using breakout, it supports up to 240 x 10GbE or 25GbE ports, with FC and RS FEC.
Q: What does the front-to-rear airflow and dual AC variant mean?
A: This SKU draws cool air in from the front and exhausts it at the rear, and includes 1+1 redundant hot-swap AC power supplies along with N+1 hot-swap fan trays.
Q: How much packet buffer does it have?
A: It has 24GB of packet buffer memory using a VOQ architecture, which suits bursty and high-fan-in traffic patterns.
Q: What software does it run and which routing protocols are supported?
A: It runs Arista EOS. The 7280R family supports MPLS, SR-MPLS and BGP routing.
Q: What is AlgoMatch used for?
A: AlgoMatch accelerates large-scale ACL and forwarding-table lookups, helping the switch handle large routing and policy tables at line rate.
