Arista DCS-7280CR2A-60# | 7280CR2A-60 60x100GbE QSFP100 Switch Router, AlgoMatch
Arista DCS-7280CR2A-60# | 7280CR2A-60 60x100GbE QSFP100 Switch Router, AlgoMatch
Authorised Arista Partner
SKU:DCS-7280CR2A-60#
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7280CR2A-60# is a 60-port 100GbE QSFP100 data center switch router with 12 Tbps of wire-speed switching and deep packet buffers. It suits high-performance spine, leaf and routing roles. This SKU uses AlgoMatch for scalable ACL, routing and forwarding table lookups, and is supplied as a configurable chassis, with fans and power supplies ordered separately to match your airflow direction and PSU type.
Each QSFP100 port supports 100GbE, 40GbE, or breakout to 4x10GbE/25GbE, giving flexible port density for mixed-speed data center fabrics. The switch runs Arista EOS and offers hot-swappable, redundant power supplies and fans for resilient operation.
Features
Features
- Deep-buffer, high-density 100GbE switch router for data center spine, leaf and routing roles
- AlgoMatch technology for scalable ACL, routing and forwarding table lookups
- Arista EOS network operating system
- Quad 10GbE/25GbE breakout mode on the QSFP100 ports
- Hot-swappable, redundant power supplies and fans with configurable airflow
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 60 x QSFP100 ports (100GbE, 40GbE, or 4x10GbE/25GbE breakout)
- Up to 60 x 100GbE, 120 x 50GbE, 60 x 40GbE, or 240 x 25GbE/10GbE ports
- 12 Tbps wire-speed switching capacity
- 5.02 Bpps forwarding rate
- Latency from 3.8us
- 24GB packet buffer
- 16GB system memory, multi-core x86 CPU
- 4GB flash storage, 1 USB port
- 1 x 100/1000 management port, 1 x RS-232 (RJ-45) console
- Hot-swap 2 x PSU (1+1 redundant) and 4 x fans (N+1 redundant)
- AlgoMatch lookup technology
- Fans and PSUs ordered separately
FAQs
Q: Are fans and power supplies included with the DCS-7280CR2A-60#?
A: No. This SKU is the configurable chassis, so the fans and power supplies are ordered separately. This lets you select the airflow direction and PSU type that suit your rack.
Q: What port speeds does the DCS-7280CR2A-60# support?
A: It has 60 QSFP100 ports. Each port runs at 100GbE or 40GbE, or can break out to 4x10GbE/25GbE, for up to 240 x 25GbE/10GbE ports in total.
Q: What is AlgoMatch?
A: AlgoMatch is Arista's lookup technology that enables scalable ACL, routing and forwarding table lookups on the 7280R series.
Q: Does this switch support redundant power and cooling?
A: Yes. It uses hot-swap 2 x PSU in a 1+1 redundant arrangement and 4 x fans in an N+1 redundant arrangement.
Q: What operating system does it run?
A: It runs Arista EOS, the same network operating system used across Arista data center platforms.
Q: What is the packet buffer size?
A: The switch includes a 24GB packet buffer, suited to deep-buffer data center and routing workloads.
