Arista DCS-7280CR2-60-F | 7280R2 60-Port 100GbE QSFP Switch Router, Front-to-Rear, Dual AC

Arista DCS-7280CR2-60-F | 7280R2 60-Port 100GbE QSFP Switch Router, Front-to-Rear, Dual AC

Authorised Arista Partner

SKU:DCS-7280CR2-60-F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7280CR2-60-F is a 2RU 100GbE data centre switch router from the 7280R2 family, built around 60 x QSFP100 ports with wire-speed, non-blocking performance. A deep VOQ packet buffer of 24 GB, 12 Tbps switching capacity and a 5.02 Bpps forwarding rate make it well suited to spine, leaf and routed data centre edge deployments.

This variant uses front-to-rear airflow with two hot-swappable 1900W AC power supplies and four hot-swappable fan modules for resilient operation. It runs Arista EOS, supports large IPv4 and IPv6 routing tables, and offers flexible port breakout to 50GbE, 40GbE, 25GbE and 10GbE speeds.

Features

- Wire-speed, non-blocking VOQ architecture with deep buffers
- Six of the 100G QSFP ports can be configured as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE
- Redundant hot-swappable power supplies and fans
- Front-to-rear airflow for standard data centre hot and cold aisle layouts
- Runs the Arista EOS network operating system

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 60 x QSFP100 ports (100/50/40/25/10GbE capable)
- Switching capacity: 12 Tbps
- Forwarding rate: 5.02 Bpps
- Packet buffer: 24 GB (VOQ deep buffer)
- Latency: from 3.8 µs
- MAC address table: 768K entries
- IPv4 LPM routes: 1.3M, IPv6 LPM routes: 1M
- 2 x PWR-1900AC-F 1900W hot-swappable AC power supplies (100-240 VAC)
- 4 x FAN-7002H-F hot-swappable fan modules, front-to-rear airflow
- 1 x RJ45 serial console and 1 x out-of-band management port
- Multi-core x86 CPU with 16 GB system memory
- 2RU form factor

FAQs

Q: What airflow direction does the DCS-7280CR2-60-F use?
A: This model uses front-to-rear airflow with four hot-swappable FAN-7002H-F fan modules.

Q: What power supplies are included?
A: It is configured with two PWR-1900AC-F 1900W hot-swappable AC power supplies accepting 100-240 VAC, providing power redundancy.

Q: Can the 100G ports run at lower speeds?
A: The QSFP100 ports support 100/50/40/25/10GbE operation, and six of the ports can be configured as 6x100GbE, 24x25GbE, 6x40GbE or 24x10GbE breakout.

Q: What operating system does this switch run?
A: It runs Arista EOS on a multi-core x86 CPU with 16 GB of system memory.

Q: How much packet buffer does it have?
A: It has a 24 GB VOQ deep packet buffer, which helps absorb bursty traffic in data centre and routing roles.

Q: What is the form factor and management access?
A: It is a 2RU switch with an RJ45 serial console port and a dedicated out-of-band management port.
