Arista DCS-7260QX-64-F | 7260X 64-Port 40G QSFP+ Switch, 2x SFP+, Front-to-Rear, 2x AC
Arista DCS-7260QX-64-F | 7260X 64-Port 40G QSFP+ Switch, 2x SFP+, Front-to-Rear, 2x AC
Authorised Arista Partner
SKU:DCS-7260QX-64-F
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7260QX-64-F is a 2RU fixed-configuration 40GbE data centre switch from the 7260X Series, with 64 QSFP+ ports and 2 SFP+ ports. It delivers wire-speed Layer 2 and Layer 3 forwarding with low latency from 550ns, making it well suited to high-density leaf, spine and aggregation roles in 40G data centre fabrics. This variant ships with front-to-rear airflow and dual AC power supplies.
The switch provides 5.12 Tbps of switching capacity, a 16 MB shared dynamic packet buffer and runs Arista EOS, with CloudVision, Zero Touch Provisioning, VXLAN and MLAG support for scalable, automated deployments. Redundant, hot-swappable power supplies and fan modules support continuous operation in demanding rack environments.
Features
Features
- Wire-speed Layer 2 and Layer 3 forwarding
- Under 7W per port power consumption
- Over 93% efficient power supplies
- 1+1 redundant, hot-swappable power and N+1 redundant, hot-swappable fans
- Multi-Chassis Link Aggregation (MLAG)
- VXLAN support
- OpenFlow, DirectFlow and eAPI
- CloudVision and Zero Touch Provisioning (ZTP)
- LANZ microburst detection
- Multi-core x86 CPU with 4GB or 8GB DRAM; user applications can run in a VM
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 64 x 40GbE QSFP+ ports
- 2 x SFP+ (1/10GbE) ports
- Switching capacity 5.12 Tbps
- Forwarding rate up to 3.3 Bpps
- Latency from 550ns (cut-through)
- 16 MB shared dynamic packet buffer
- 136K MAC entries
- 4096 VLANs
- 2RU form factor, front-to-rear airflow
- 2 x 1100W AC power supplies (PWR-1100AC-F), 1+1 redundant and hot-swappable
- 4 x FAN-7002-F fan modules, N+1 redundant and hot-swappable
- Management: 1 x RJ45 out-of-band Ethernet, 1 x RS-232 RJ45 serial, 1 x USB
- Arista EOS
FAQs
Q: What port configuration does the DCS-7260QX-64-F offer?
A: It provides 64 x 40GbE QSFP+ ports and 2 x SFP+ ports supporting 1/10GbE in a 2RU chassis.
Q: Does this model have front-to-rear airflow?
A: Yes. The -F variant ships with front-to-rear airflow, using PWR-1100AC-F power supplies and FAN-7002-F fan modules.
Q: Is power and cooling redundant?
A: Yes. It includes two 1100W AC power supplies in a 1+1 redundant, hot-swappable configuration, and four fan modules in an N+1 redundant, hot-swappable arrangement.
Q: What switching performance can I expect?
A: The switch delivers 5.12 Tbps of switching capacity, forwarding rates up to 3.3 Bpps and latency from 550ns in cut-through mode.
Q: What network operating system does it run?
A: It runs Arista EOS, with support for CloudVision, Zero Touch Provisioning, eAPI, OpenFlow and DirectFlow for automation and programmability.
Q: Does it support overlay and high-availability features?
A: Yes. It supports VXLAN and Multi-Chassis Link Aggregation (MLAG), making it suitable for scalable leaf-spine data centre designs.
