Arista DCS-7250QX-64-D# | 7250QX 64-Port 40GbE QSFP+ Switch, SSD, No Fans/PSU
Arista DCS-7250QX-64-D# | 7250QX 64-Port 40GbE QSFP+ Switch, SSD, No Fans/PSU
Authorised Arista Partner
SKU:DCS-7250QX-64-D#
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7250QX-64-D# is a 2RU 64-port 40GbE QSFP+ data centre switch built for leaf or collapsed-spine tiers. It delivers wire-speed Layer 2 and Layer 3 forwarding with up to 5 Tbps of switching capacity and latency below 2 microseconds, and supports up to 256 x 10GbE using breakout. This SKU is the chassis with built-in SSD only, supplied without fans or power supplies, which are ordered separately.
The switch runs Arista EOS and uses a shared dynamic packet buffer to absorb congestion in east-west heavy fabrics. The built-in SSD supports advanced logging, data capture and other on-switch services. Hot-swappable N+1 fans and redundant hot-swappable power supplies are available as separate options, with front-to-rear or rear-to-front airflow choices.
Features
Features
- Runs Arista EOS
- Wire-speed Layer 2 and Layer 3 forwarding across all ports
- Shared dynamic packet buffer to absorb congestion
- Built-in SSD for advanced logging, data capture and on-switch services
- Supports N+1 redundant hot-swappable fans (ordered separately)
- Supports redundant hot-swappable power supplies with over 93% efficiency (ordered separately)
- Front-to-rear or rear-to-front airflow options
- Suited to large leaf and spine networks with east-west traffic
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 64 x QSFP+ 40GbE ports
- Up to 256 x 10GbE using breakout
- Up to 5 Tbps switching capacity
- 3840 million packets per second
- Wire-speed Layer 2 and Layer 3 forwarding
- Latency below 2 microseconds
- 12MB shared packet buffer per group of ports, dynamically allocated
- Typical power under 14W per 40GbE port
- 2RU form factor
- Built-in SSD included
- Fans and power supplies not included (chassis only)
FAQs
Q: Does the DCS-7250QX-64-D# include fans and power supplies?
A: No. This SKU is the chassis with built-in SSD only. Fans and power supplies are separate options and must be ordered to complete the switch.
Q: How many 10GbE ports can this switch provide?
A: Each of the 64 QSFP+ ports can run as 40GbE or be broken out, giving up to 256 x 10GbE ports at wire speed.
Q: Does this model include an SSD?
A: Yes. The built-in SSD is included in this SKU and supports advanced logging, data capture and other on-switch services.
Q: What operating system does it run?
A: The 7250QX-64 runs Arista EOS.
Q: Where is this switch typically deployed?
A: It is suited to leaf or collapsed-spine tiers in data centre networks, particularly where large east-west traffic volumes are expected.
Q: What airflow options are available?
A: Front-to-rear and rear-to-front airflow options are available through the choice of fan modules, which are ordered separately.
