Arista DCS-7150SC-24-CLD-R | 7150SC-24 24-Port 10G SFP+ Switch, Rear-to-Front, 120GB SSD
Arista DCS-7150SC-24-CLD-R | 7150SC-24 24-Port 10G SFP+ Switch, Rear-to-Front, 120GB SSD
Authorised Arista Partner
SKU:DCS-7150SC-24-CLD-R
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista 7150SC-24 is an ultra low latency 1RU layer 2/3/4 wire-speed 1/10GbE SFP+ switch with 24 SFP+ ports, 480Gbps throughput and port-to-port latency from 350ns. This DCS-7150SC-24-CLD-R variant has rear-to-front airflow, a high precision clock, a 120GB SSD and dual hot-swappable AC power supplies, making it well suited to financial ECNs, HPC clusters and cloud data centres.
It pairs a quad-core x86 control plane with 4GB DRAM and a 9.5MB dynamic packet buffer. IEEE 1588 Precision Time Protocol support with the integrated high-precision oscillator, LANZ microburst analysis and DANZ tap aggregation give operators the timing accuracy and visibility needed for latency-sensitive environments. The 7150SC family also supports wire-speed VXLAN gateway functions and AgilePorts for 10G to 40G adaptation.
Features
Features
- Ultra low latency from 350ns port to port
- IEEE 1588 Precision Time Protocol with integrated high-precision oscillator
- LANZ latency and microburst analysis
- Advanced multi-port mirroring and DANZ tap aggregation
- Wire-speed VXLAN gateway
- AgilePorts for 10G to 40G adaptation
- Dynamic buffer allocation
- Zero Touch Provisioning, VMTracer, self-configure/recover from USB
- User applications can run in a VM; extensible with bash, python and C++
- RoHS compliant (EU 2019/172)
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 24 x 1/10GbE SFP+ ports
- Throughput 480Gbps; 360 Mpps forwarding
- Latency from 350ns
- Quad-core x86 CPU
- 4GB DRAM, 8GB Flash
- 120GB SSD
- 9.5MB dynamic packet buffer
- 64,000 MAC addresses
- 1 x 100/1000 management port, 1 x RS-232 RJ-45 serial, 1 x USB
- 2 x hot-swappable AC PSUs (1+1 redundant)
- 4 x hot-swappable fans (N+1 redundant)
- Rear-to-front airflow
- High precision oscillator (clock)
- 1RU, 19" x 1.75" x 16
- Typical power 191W, maximum 334W
FAQs
Q: What port types does the DCS-7150SC-24-CLD-R support?
A: It provides 24 SFP+ ports that support 1GbE and 10GbE, so you can mix 1G and 10G optics or direct attach cables as needed.
Q: What does the CLD-R in the part number mean for airflow and power?
A: This variant uses rear-to-front airflow and ships with two hot-swappable AC power supplies in a 1+1 redundant arrangement, along with N+1 redundant fans.
Q: Does this switch support precision time synchronisation?
A: Yes. It supports IEEE 1588 Precision Time Protocol and includes an integrated high-precision oscillator, which suits timing-sensitive financial and HPC deployments.
Q: How much latency does the 7150SC-24 add?
A: Port-to-port latency is from 350ns, which is why it is commonly selected for low latency trading and cluster networks.
Q: Can I run my own applications on the switch?
A: Yes. User applications can run in a VM on the switch, and the platform is extensible with bash, python and C++.
Q: What storage and memory does it include?
A: This model includes a 120GB SSD, 4GB DRAM and 8GB Flash, powered by a quad-core x86 CPU.
