Arista DCS-7150SC-24-CLD# | 7150SC 24-Port 10G SFP+ Switch, Precision Clock, 120GB SSD

Arista DCS-7150SC-24-CLD# | 7150SC 24-Port 10G SFP+ Switch, Precision Clock, 120GB SSD

Authorised Arista Partner

SKU:DCS-7150SC-24-CLD#

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7150SC-24-CLD# is an ultra-low-latency 1RU Layer 2/3/4 switch with 24 x 1/10GbE SFP+ ports, built for trading, HPC and latency-sensitive data centre environments. This SC variant includes a high-precision oscillator clock and a 120GB SSD, with latency from 350 ns and switching capacity up to 480 Gbps.

This chassis ships without fans or power supplies, which are ordered separately to suit your airflow and power configuration. It runs Arista's extensible Linux-based EOS, with IEEE 1588 PTP hardware timing, LANZ microburst analysis and ultra-low-latency NAT for deterministic, high-performance networking.

Features

- Same ultra-low latency for L2 and L3 forwarding
- Cut-through switching with low latency at 1, 10 and 40GbE
- Low jitter for unicast and multicast traffic
- Dynamic buffer allocation
- Line-rate NAT in under 1 microsecond
- IEEE 1588 PTP (boundary and transparent clock modes) with hardware timing
- LANZ microburst analysis
- Zero Touch Provisioning
- Extensible Linux-based EOS supporting bash, python and C++, with user applications able to run in a VM

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 24 x 1/10GbE SFP+ ports
- Switching capacity up to 480 Gbps
- Up to 360 Mpps L2/L3 forwarding
- Latency from 350 ns
- Integrated high-precision oscillator clock
- 120GB SSD
- Multi-core x86 CPU, 4GB DRAM, 4GB flash
- MAC address table: 64,000 entries
- Maximum power 334 W, typical 191 W
- 1RU rack-mountable
- No fans or PSU included (sold separately)
- RoHS compliant

FAQs

Q: Does the DCS-7150SC-24-CLD# include fans and power supplies?
A: No. This SKU is supplied without fans and without power supplies. Both must be ordered separately to complete the chassis.

Q: What port types does this switch provide?
A: It provides 24 x 1/10GbE SFP+ ports, accepting 1G and 10G SFP+ optics and direct-attach cables.

Q: What does the SC designation add over other 7150S models?
A: SC models add a multi-core x86 CPU with 4GB DRAM and 4GB flash, plus the integrated high-precision clock and a 120GB SSD on this variant.

Q: What switching performance can I expect?
A: Up to 480 Gbps switching capacity and up to 360 Mpps L2/L3 forwarding, with latency from 350 ns.

Q: Does it support precision time synchronisation?
A: Yes. It supports IEEE 1588 PTP in boundary and transparent clock modes with hardware timing, backed by the integrated high-precision oscillator.

Q: What is the power consumption?
A: Typical power draw is 191 W and maximum is 334 W, so size the separately ordered power supplies accordingly.
