Arista DCS-7150S-24-CL# | 7150S-24 24-Port 10G SFP+ Switch, Precision Clock, No Fans/PSU
Arista DCS-7150S-24-CL# | 7150S-24 24-Port 10G SFP+ Switch, Precision Clock, No Fans/PSU
Authorised Arista Partner
SKU:DCS-7150S-24-CL#
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista 7150S-24 is an ultra low latency 1RU Layer 2/3/4 10G SFP+ switch with 24 SFP+ ports, each running at 1G or 10G. This SKU (DCS-7150S-24-CL#) includes the integrated high precision clock for accurate timing and ships without fans or power supplies, so it suits builds where airflow and PSU options are specified separately.
Built for financial trading, HPC and latency-sensitive data centre environments, it delivers 480 Gbps throughput, 360 Mpps forwarding and latency from 350 ns. It runs Arista EOS and supports IEEE 1588 PTP, LANZ microburst analysis, wire-speed NAT and VXLAN gateway functions. It requires two hot-swap PSUs and four hot-swap fans, ordered separately.
Features
Features
- Integrated high precision oscillator for accurate timing with extended holdover
- IEEE 1588 PTP for hardware-based, nanosecond-accuracy time distribution
- AgilePorts: each SFP+ interface supports 100M-10G across a range of optics
- LANZ latency and microburst analysis
- Wire-speed NAT and VXLAN gateway
- Advanced multi-port mirroring suite with in-switch capture, filtering and time-stamping
- Dynamic buffer allocation
- 32-way MLAG and ECMP routing
- EOS Zero Touch Provisioning (ZTP), Stateful Fault Repair and live software patching
- Color-coded hot-swap PSUs and fans common to Arista 1RU devices
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 24 x 1/10GbE SFP+ ports (100M supported with TX transceivers)
- 480 Gbps throughput
- 360 Mpps packet forwarding rate
- Latency from 350 ns (SFP+ ports)
- Dual-core x86 CPU
- 4 GB system memory, 2 GB flash
- 9.5 MB dynamic packet buffer
- 1 x 10/100/1000 management port, 1 x RS-232 serial (RJ-45), 1 x USB
- 1RU, 19 in rack mount
- Requires 2 hot-swap PSUs (1+1) and 4 hot-swap fans (N+1), sold separately
- Typical/max power draw 191 W / 334 W
- Integrated high precision oscillator with IEEE 1588 PTP (boundary and transparent modes)
- Runs Arista EOS (minimum EOS 4.11.0)
FAQs
Q: Does the DCS-7150S-24-CL# include power supplies and fans?
A: No. This SKU ships without fans or power supplies. It requires two hot-swap PSUs (1+1) and four hot-swap fans (N+1), which are ordered separately.
Q: What does the CL in this part number mean?
A: This variant includes the integrated high precision oscillator, which provides accurate timing with extended holdover and works alongside IEEE 1588 PTP.
Q: Can the SFP+ ports run at 1G as well as 10G?
A: Yes. Each of the 24 SFP+ ports supports 1G or 10G depending on the optic fitted, and 100M is supported with TX transceivers.
Q: What is the latency of the 7150S-24?
A: Latency starts from 350 ns on the SFP+ ports, which makes it suited to trading and other latency-sensitive applications.
Q: Which operating system does it run?
A: It runs Arista EOS, with a minimum release of EOS 4.11.0.
Q: What management interfaces are provided?
A: There is one 10/100/1000 management port, one RS-232 serial console port (RJ-45) and one USB port.
