Arista DCS-7130LBR-48S6QD-R | 7130LBR Layer 1 Switch, 48x SFP+, 6x QSFP-DD, Dual VU9P-3 FPGA

Arista DCS-7130LBR-48S6QD-R | 7130LBR Layer 1 Switch, 48x SFP+, 6x QSFP-DD, Dual VU9P-3 FPGA

Authorised Arista Partner

SKU:DCS-7130LBR-48S6QD-R

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista 7130LBR-48S6QD is a 1RU Layer 1 Application+ switch with 48 x SFP+ ports, 6 x QSFP-DD ports and two user-programmable Xilinx Virtex UltraScale+ VU9P-3 FPGAs. It combines an ultra-low-latency Layer 1 crosspoint, with latency from 4 ns, and an integrated full-featured L2/L3 switch, making it suited to trading, replication and monitoring deployments.

This rear-to-front airflow model with dual AC power supplies provides up to 1.5 Tbps of L2/L3 forwarding, 96 x 10/25GbE lanes and signal regeneration, media conversion and port mirroring. Each QSFP-DD port can break out to 2 x 40GbE or 8 x 10/25GbE, and Arista EOS on a high-performance x86 control plane supports telemetry and custom FPGA application logic.

Features

- Signal regeneration, media conversion and port mirroring
- Telemetry and layer 1+ statistics on each link
- Dynamic patching and link management
- Wire-speed L2/L3 forwarding with BGP, OSPF and PIM support
- Dual application FPGAs for custom low-latency logic
- EOS features such as Zero Touch Provisioning and LANZ, with Linux-based tools running natively
- Internal PPS distribution network

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 48 x SFP+ (or SFP28) ports plus 6 x QSFP-DD ports (8x 10/25G NRZ each)
- 96 x 10/25GbE lanes, 18 x 25GbE internal switch interfaces
- Dual Xilinx Virtex UltraScale+ VU9P-3 FPGAs
- Layer 1 latency from 4 ns; L1 replication from 6 ns
- Up to 1.5 Tbps L2/L3 forwarding via Jericho2C switch silicon
- Each QSFP-DD can break out to 2 x 40GbE or 8 x 10/25GbE
- 2 front-panel SMA ports for PPS (1 in, 1 out)
- 1RU form factor, rear-to-front airflow, 2 x AC PSU
- Power draw 391 W typical, 650 W maximum
- High-performance x86 control plane running Arista EOS

FAQs

Q: What is the Layer 1 latency of the DCS-7130LBR-48S6QD-R?
A: Layer 1 latency starts from 4 ns, and Layer 1 replication starts from 6 ns.

Q: How many FPGAs does this switch include and are they programmable?
A: It includes two Xilinx Virtex UltraScale+ VU9P-3 FPGAs that are user-programmable for custom low-latency application logic.

Q: Can the QSFP-DD ports be broken out?
A: Yes. Each QSFP-DD port can break out to 2 x 40GbE or 8 x 10/25GbE lanes.

Q: What airflow and power configuration does this SKU use?
A: This model is 1RU with rear-to-front airflow and two AC power supplies. Power draw is 391 W typical and 650 W maximum.

Q: Does it include a Layer 2/3 switch as well as Layer 1 functions?
A: Yes. An integrated Jericho2C switch provides up to 1.5 Tbps of wire-speed L2/L3 forwarding with BGP, OSPF and PIM support, running Arista EOS.

Q: Does it support precision timing inputs and outputs?
A: It has two front-panel SMA ports for PPS, one input and one output, plus an internal PPS distribution network.
