Arista DCS-7130LBR-48S6QD-F | 7130LBR Layer 1+ FPGA Switch, 48x SFP+, 6x QSFP-DD, Front-to-Rear

Arista DCS-7130LBR-48S6QD-F | 7130LBR Layer 1+ FPGA Switch, 48x SFP+, 6x QSFP-DD, Front-to-Rear

Authorised Arista Partner

SKU:DCS-7130LBR-48S6QD-F

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista DCS-7130LBR-48S6QD-F is a 1RU Layer 1+ composable switch built for ultra-low-latency, FPGA-accelerated applications such as trading and other latency-sensitive workloads. It provides 48 x SFP+ front-panel ports and 6 x QSFP-DD ports, with a Layer 1 crosspoint delivering latency from 4 ns. This -F model uses front-to-rear airflow and ships with 2 x AC power supplies.

The platform pairs a Broadcom Jericho 2C R-series switch chip with two Xilinx UltraScale+ VU9P-3 FPGAs, each backed by 32GB of DDR4 memory. It runs Arista EOS and gives development teams a composable base for custom FPGA network applications alongside deep-buffer Layer 2 and Layer 3 forwarding of up to 1.5 Tbps.

Features

- Layer 1 crosspoint switching combined with FPGA application hosting
- Runs Arista EOS, with a Linux-based architecture, Zero Touch Provisioning, LANZ and automation tooling
- Composable platform for developing custom FPGA network applications
- R-series Jericho 2C chip provides deep-buffer L2/L3 forwarding
- Dual hot-swappable AC power supplies with front-to-rear airflow

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- 48 x SFP+ front-panel ports (10G)
- 6 x QSFP-DD ports (10G NRZ, each breakable out to 8 x 10/25G or 2 x 40GbE)
- Layer 1 crosspoint with 96 x 10/25G lanes and 18 interfaces to the internal switch
- 2 x Xilinx UltraScale+ VU9P-3 FPGAs
- 32GB DDR4 per FPGA (4 x 8GB DDR4-2400 ECC)
- 48 x 10GbE FPGA crosspoint interfaces per FPGA
- Layer 1 latency from 4 ns
- Up to 1.5 Tbps L2/L3 forwarding (R-series switch)
- OCXO clock; PPS in/out 2/2
- Form factor 1RU; 48.3 x 4.4 x 65.8 cm; 14.8 kg
- Typical power draw 391 W, maximum 650 W (AC PSU)
- Front-to-rear airflow, 2 x AC power supplies

FAQs

Q: What FPGAs does the DCS-7130LBR-48S6QD-F include?
A: It includes two Xilinx UltraScale+ VU9P-3 FPGAs, each with 32GB of DDR4-2400 ECC memory and 48 x 10GbE crosspoint interfaces.

Q: What is the airflow direction and power configuration of this model?
A: The -F model uses front-to-rear airflow and has 2 x AC power supplies. Typical power draw is 391 W and maximum is 650 W.

Q: What port types does it offer?
A: It has 48 x SFP+ ports for 10G and 6 x QSFP-DD ports running 10G NRZ. Each QSFP-DD port can be broken out to 8 x 10/25G or 2 x 40GbE.

Q: What is the Layer 1 latency?
A: The Layer 1 crosspoint provides latency from 4 ns, suited to latency-sensitive trading and similar workloads.

Q: What operating system does it run?
A: It runs Arista EOS, which provides a Linux-based architecture, Zero Touch Provisioning, LANZ and automation tooling.

Q: What is the switching capacity of the integrated switch chip?
A: The Broadcom Jericho 2C R-series switch chip provides up to 1.5 Tbps of Layer 2 and Layer 3 forwarding with deep buffers.
