Arista

Arista DCS-7050CX4M-48D8-R | 7050X4 100G QSFP28 Switch, 8x 400G QSFP-DD, MACsec

Arista DCS-7050CX4M-48D8-R | 7050X4 100G QSFP28 Switch, 8x 400G QSFP-DD, MACsec

Authorised Arista Partner

SKU:DCS-7050CX4M-48D8-R

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Arista 7050X4 DCS-7050CX4M-48D8-R is a 2RU data centre leaf and spine switch with 48x 100GbE QSFP28 ports and 8x 400GbE QSFP-DD ports, delivering wire-speed L2 and L3 forwarding with line-rate MACsec encryption. This rear-to-front airflow variant ships with dual AC power supplies, suited to hot-aisle deployments where server NICs face the cold aisle.

Each QSFP-DD port supports 400, 200, 100 and 40GbE with breakout modes, so the switch scales from 10G and 25G server access through to 100G and 400G uplinks. It runs Arista EOS with CloudVision support and is optimised for top-of-rack leaf use cases with 50G and 100G PAM4 server NICs.

Features

- Line-rate MACsec hardware encryption
- Flexible 10/25/40/50/100/200/400GbE speeds using breakouts
- Wire-speed L2 and L3 forwarding
- Runs Arista EOS with CloudVision support
- Optimised for top-of-rack leaf and spine deployments with 50G and 100G PAM4 server NICs
- Rear-to-front airflow with dual AC power supplies

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 48 x 100GbE QSFP28 ports
- 8 x 400GbE QSFP-DD ports, each supporting 400/200/100/40GbE plus breakout modes
- 2RU rackmount form factor
- Up to 8.0 Tbps L2/L3 throughput
- Up to 2.7 Bpps packet forwarding
- Latency from 900ns
- 82MB total system buffer
- Up to 72 x 100G or 72 x 10G logical ports via breakouts
- MACsec encryption on 56 ports
- Typical power draw 390W, PWR-1512-AC power supplies, max 740W
- Quad-core x86 CPU
- Rear-to-front airflow, 2 x AC power supplies
- Dimensions 48.3 x 8.8 x 66.8 cm, weight 16.0 kg

FAQs

Q: What airflow and power configuration does the DCS-7050CX4M-48D8-R have?
A: This -R variant has rear-to-front airflow and ships with two AC power supplies. Typical power draw is 390W, with PWR-1512-AC supplies rated to a maximum of 740W.

Q: Does this switch support MACsec encryption?
A: Yes. It provides line-rate hardware MACsec encryption on 56 ports.

Q: What speeds do the QSFP-DD ports support?
A: Each of the 8 QSFP-DD ports supports 400, 200, 100 and 40GbE, plus breakout modes for lower-speed connections.

Q: Can it connect to 10G and 25G devices?
A: Yes. Breakout configurations allow 10/25/40/50/100/200/400GbE speeds, with up to 72 x 10G logical ports available using breakouts.

Q: What operating system and management does it use?
A: It runs Arista EOS and supports CloudVision for centralised management and automation.

Q: Is it suitable for leaf and spine deployments?
A: Yes. It is designed for top-of-rack leaf and spine roles, with 48 x 100G downlinks and 8 x 400G ports for uplinks or high-speed fabric connections.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
