Arista DCS-7020SR-32C2-R | 7020R 32-Port 10G SFP+ Switch, 2x 100G, Rear-to-Front, AC
Arista DCS-7020SR-32C2-R | 7020R 32-Port 10G SFP+ Switch, 2x 100G, Rear-to-Front, AC
Authorised Arista Partner
SKU:DCS-7020SR-32C2-R
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7020SR-32C2-R is a 1RU half-depth data centre switch from the Arista 7020R Series, delivering 32 x 10GbE SFP+ ports and 2 x 100GbE QSFP100 uplinks. This rear-to-front airflow variant with AC power supplies suits hot-aisle cold-aisle racks where the ports face the cold aisle behind the server rear.
Built around a 3GB deep packet buffer, it absorbs traffic bursts and avoids head-of-line blocking in cloud, virtualised and traditional data centre designs. It runs Arista EOS and offers hot-swappable redundant power supplies and N+1 fans, all in a compact low-power chassis.
Features
Features
- Runs Arista EOS for big data, cloud, virtualised and traditional data centre designs
- Deep buffering to absorb bursts and avoid head-of-line blocking
- Hot-swappable, redundant power supplies and fans
- Over 90% efficient power supplies, with AC or DC power options
- PPS clock input/output ports
- Tool-less rails with 2-post and 4-post mounting
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 32 x 10GbE SFP+ ports
- 2 x 100GbE QSFP100 uplinks
- 1 x 1000BASE-T out-of-band management port and RJ-45 console port
- Up to 300 Mpps packet forwarding, latency from 3.8 us
- 3GB packet buffer
- Up to 256K MAC entries, 128-way ECMP, 64-port MLAG
- Multi-core x86 CPU, 8GB DRAM, 4GB flash (min)
- 1+1 hot-swappable power supplies (PWR-400AC or PWR-400-DC), front-removable
- Power draw 160 W typical / 189 W maximum
- N+1 redundant hot-swappable fans, rear-to-front airflow
- Dimensions 48.3 x 4.4 x 34.7 cm (1RU, 13.6 in deep), weight 6.4 kg (14.4 lbs)
- Operating temperature 0 to 40°C
FAQs
Q: What does the -R suffix mean on the DCS-7020SR-32C2-R?
A: The -R denotes rear-to-front airflow, so air is drawn in at the rear of the chassis and exhausted at the front. This SKU is supplied with AC power.
Q: What uplink options does this switch provide?
A: It has 2 x 100GbE QSFP100 uplinks alongside the 32 x 10GbE SFP+ ports.
Q: Does it support redundant power?
A: Yes. It uses 1+1 hot-swappable, front-removable power supplies (PWR-400AC or PWR-400-DC) and N+1 hot-swappable fans.
Q: How much packet buffer does it have?
A: It has a 3GB packet buffer, which helps absorb traffic bursts and avoid head-of-line blocking.
Q: What is the physical size and mounting?
A: It is a 1RU half-depth chassis, 48.3 x 4.4 x 34.7 cm and 6.4 kg, with tool-less rails supporting 2-post and 4-post mounting.
Q: What operating system does it run?
A: It runs Arista EOS, the same software used across Arista data centre switching.
