Arista DCS-7020SR-32C2-F | 7020SR 32-Port 10G SFP+ Switch, 2x 100G QSFP100, Front-to-Rear
Arista DCS-7020SR-32C2-F | 7020SR 32-Port 10G SFP+ Switch, 2x 100G QSFP100, Front-to-Rear
Authorised Arista Partner
SKU:DCS-7020SR-32C2-F
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7020SR-32C2-F is a 1RU deep-buffer data centre switch from the Arista 7020R Series, with 32 x 1/10GbE SFP+ ports and 2 x 100G QSFP100 uplinks. It uses a Virtual Output Queue (VOQ) architecture with a 3GB dynamic packet buffer to avoid head-of-line blocking and packet drops under congestion. This -F variant ships with front-to-rear airflow fan modules.
Running Arista EOS, the switch delivers up to 1.04 Tbps throughput and up to 300 Mpps forwarding at wire speed for L2/L3 unicast and multicast. It includes two redundant PSU slots and N+1 fans, supports LANZ microburst detection, and integrates with CloudVision for management. Power supplies are sold separately (PWR-400AC or PWR-400-DC).
Features
Features
- Deep buffer Virtual Output Queue (VOQ) architecture eliminates head-of-line blocking
- Arista EOS with single image consistency across Arista switches
- LANZ latency analyser for microburst detection
- Accelerated sFlow support on 7020SR models
- CloudVision management integration
- Wire-speed L2/L3 unicast and multicast
- Redundant, hot-swappable power supplies and fans
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 32 x 1/10GbE SFP+ ports
- 2 x 100G QSFP100 uplink ports (also supports 40GbE; up to 8 x 25GbE via breakout)
- Throughput up to 1.04 Tbps
- Up to 300 Mpps forwarding rate
- Latency from 3.8 microseconds
- 3GB dynamic deep packet buffer
- 8GB system memory, quad-core CPU
- 1 x 100/1000 management port, USB and RS-232 console
- 1RU; 48.3 x 4.4 x 34.7 cm; 6.4 kg (14.4 lbs)
- Typical power draw 160 W, maximum 189 W
- 2 PSU slots, redundant; supports PWR-400AC and PWR-400-DC (PSUs sold separately)
- 2 x FAN-7001C-F fan modules included (N+1), front-to-rear airflow
- Operating temperature 0 to 40°C
FAQs
Q: Are power supplies included with the DCS-7020SR-32C2-F?
A: No. The switch has two redundant PSU slots and the power supplies are sold separately. Supported models are PWR-400AC and PWR-400-DC. The two FAN-7001C-F fan modules are included.
Q: What does the -F suffix mean?
A: The -F suffix denotes front-to-rear airflow. The included FAN-7001C-F fan modules move air from the front of the switch to the rear, which suits hot-aisle and cold-aisle rack layouts that draw air in from the port side.
Q: What speeds do the uplink ports support?
A: The 2 x QSFP100 uplink ports run at 100GbE and also support 40GbE. They can be broken out to up to 8 x 25GbE using suitable breakout optics or cables.
Q: Can the SFP+ ports run at 1GbE?
A: Yes. The 32 SFP+ ports support 1/10GbE operation, subject to the transceivers installed.
Q: Why choose a deep-buffer switch like the 7020SR?
A: The 3GB dynamic packet buffer and VOQ architecture absorb microbursts and congestion without head-of-line blocking, which helps with storage, big data and mixed-speed workloads. LANZ can be used to identify microbursts.
Q: What operating system does it run?
A: It runs Arista EOS, the same single-image operating system used across Arista switches, and it integrates with CloudVision for management.
