APC SUA1000XLI | Smart-UPS XL Tower UPS, 1000VA/800W, 230V, USB/Serial

APC SUA1000XLI | Smart-UPS XL Tower UPS, 1000VA/800W, 230V, USB/Serial

Authorised APC Partner

SUA1000XLI

Stock Status: Enquire

$1,559.49 inc. GST
$1,417.72 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC Smart-UPS XL SUA1000XLI is a tower, line-interactive UPS rated 1000VA/800W at 230V, built for servers, network equipment and other business-critical loads that need clean sine wave power and extended battery runtime. Management is handled over USB and RS-232 serial, and the unit includes eight IEC C13 outlets that all provide battery backup, plus two IEC jumpers.

The extended-runtime battery delivers approximately 33.9 minutes at half load and 9.7 minutes at full load, giving time for orderly shutdown or for short outages to pass. A SmartSlot interface accepts optional management cards such as network modules, and the output voltage can be configured for 220, 230 or 240V nominal.

Features

- Sine wave output for sensitive server and network equipment
- Extended-runtime battery for longer backup during outages
- All 8 outlets provide battery backup
- Management via USB port and RS-232 serial port
- SmartSlot interface for optional network management cards
- LED status indicators for unit and power status
- Audible alarm for power problems
- Includes software CD, RS-232 signalling cable, USB cable and user manual

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

FAQs

APC Replacement Battery Finder

Technical Specifications

- Capacity: 1000VA / 800W
- Nominal input and output voltage: 230V
- Input voltage range for main operations: 160-285V
- Input frequency: 50/60Hz, auto sensing
- Input connection: IEC-320 C14, 1.8 m cord
- Output connections: 8x IEC 320 C13 (battery backup), 2x IEC jumpers
- Output configurable for 220, 230 or 240V nominal
- Waveform: sine wave, output voltage distortion <5% at full load
- Crest factor: 5:1 or lower
- Surge energy rating: 320 Joules
- Runtime: 33.9 min at half load, 9.7 min at full load
- Communication: USB and RS-232 serial
- Expansion: SmartSlot interface
- Net weight: 27.3 kg

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: What is the load capacity of the SUA1000XLI?
A: It is rated for 1000VA / 800W at 230V nominal.

Q: How long will it run on battery?
A: Typical runtime is 33.9 minutes at half load and 9.7 minutes at full load.

Q: Does it have a network management option?
A: Yes. The unit has a SmartSlot interface that accepts optional APC management cards, and it also provides USB and RS-232 serial ports as standard.

Q: How many outlets does it provide and are they all battery backed?
A: It has eight IEC C13 outlets, all of which provide battery backup, plus two IEC jumpers.

Q: Is it a rack-mount or tower unit?
A: This SKU is a tower UPS. It has a net weight of 27.3 kg, so allow for a floor or sturdy shelf location.

Q: What cables are included for management?
A: The package includes a software CD, an RS-232 signalling cable, a USB cable and a user manual.
