• APC Smart-UPS C1000 with voltage and battery display, SMC1500I model
1 1

APC

APC SMC1500I | Smart-UPS C Tower UPS, 1500VA/900W, LCD, 8x IEC C13

APC SMC1500I | Smart-UPS C Tower UPS, 1500VA/900W, LCD, 8x IEC C13

Authorised APC Partner

SMC1500I

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.
End of life
This item has been replaced by SMC1500IC.

Description

The Smart-UPS C SMC1500I is a line-interactive tower UPS rated 1500VA/900W, built to protect servers, network equipment and other sensitive loads on a 230V supply. A multi-function LCD status console shows load and battery bar graphs and gives access to over 15 programmable settings, while 8 IEC C13 battery-backed outlets plus 2 IEC jumper outlets cover a typical rack or desk-side deployment.

Output is a pure sine wave on battery, which keeps active PFC power supplies in modern servers running correctly during an outage. Full-time multi-pole noise filtering and surge protection guard against spikes and lightning-induced disturbances, and a maintenance-free sealed lead-acid battery (RBC6 replacement) with temperature-compensated charging helps prolong battery life. A USB interface port allows monitoring and controlled shutdown.

Features

- Pure sine wave output on battery for compatibility with active PFC servers
- Multi-function LCD with load and battery bar graphs
- Over 15 programmable settings via the LCD, including switched outlet group control
- Green mode for high operating efficiency in good power conditions
- Cold-start capable
- Temperature-compensated battery charging to prolong battery life
- Automatic restart of loads after UPS shutdown
- Full-time multi-pole noise filtering and surge protection
- Audible alarms for on-battery, low battery and overload conditions

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

Manual

FAQs

APC Replacement Battery Finder

Technical Specifications

- Output capacity: 1500VA / 900W
- Nominal output voltage: 230V
- Topology: line-interactive, sine wave output on battery
- Output connections: 8 x IEC 320 C13 plus 2 x IEC jumper outlets, all battery backed
- Input connection: IEC-320 C14, 230V nominal, 50/60 Hz auto sensing
- Input voltage range for main operations: 180 - 287 V
- Battery: maintenance-free sealed lead-acid, replacement cartridge RBC6
- Typical recharge time: 3 hours
- Interface: USB port with multi-function LCD status and control console
- Surge energy rating: 459 Joules
- Form factor: tower, 219 mm H x 171 mm W x 439 mm D
- Net weight: 24.09 kg, colour: black

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: What type of outlets does the SMC1500I provide?
A: It has 8 IEC 320 C13 outlets and 2 IEC jumper outlets, all supported by battery backup. Equipment with standard IEC C14 plugs connects directly using C13 outlets.

Q: Does it output a pure sine wave on battery?
A: Yes. The SMC1500I is line-interactive with sine wave output on battery, which suits servers with active PFC power supplies.

Q: Which replacement battery does this UPS use?
A: It uses a single RBC6 replacement battery cartridge. The battery is a maintenance-free sealed lead-acid type.

Q: Is this a tower or rack-mount UPS?
A: It is a tower form factor unit, 219 mm high, 171 mm wide and 439 mm deep, designed for floor or desk-side placement.

Q: How can I monitor the UPS?
A: The front multi-function LCD shows status, load and battery bar graphs, and a USB interface port allows connection to a host for monitoring and controlled shutdown.

Q: What input voltage does it accept?
A: It has a 230V nominal input via an IEC-320 C14 connector and operates across a 180 - 287 V mains range before switching to battery.
