• Dell Compatible 407-BBZM-BCC 1G SFP transceiver with Blue Cable Co label
1 1

Blue Cable Co

407-BBZM-BCC | Dell Compatible 1GB Multi-Mode 550m (1000BASE-SX) Rugged / Industrial

407-BBZM-BCC | Dell Compatible 1GB Multi-Mode 550m (1000BASE-SX) Rugged / Industrial

407-BBZM-BCC

Stock Status: Enquire

$51.70 inc. GST
$47.00 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The 407-BBZM-BCC is a drop-in compatible replacement for the Dell 407-BBZM. This SFP+ transceiver is plug-and-play compatible with Dell networking equipment that supports 10GBASE-SR optics and operates in extended industrial temperature environments. - 10GBASE-SR compliance guarantees interoperability with IEEE 802.3ae 10 Gigabit Ethernet infrastructure - SFP+ form factor, 10 Gbps data rate, 850nm wavelength, multi-mode fibre, duplex LC connector, up to 300m reach on OM3 fibre - Digital Optical Monitoring (DOM) support for real-time diagnostics of optical power, temperature, laser bias current, and supply voltage - Industrial temperature rating from -40°C to 85°C enables deployment in harsh environments including outdoor installations, factory automation, and industrial control systems - Hot-pluggable design supports field installation and maintenance without network downtime - MSA compliant ensuring physical and electrical compatibility across multi-vendor SFP+ platforms

Features

• IEEE 802.3ae 10GBASE-SR compliance ensures interoperability with standards-compliant switches, routers, and optical infrastructure across mixed-vendor environments
• Industrial temperature range from -40°C to 85°C uses hardened optical and electronic components designed for outdoor deployments, industrial automation, utilities, mining, oil and gas, and intelligent transportation systems where commercial-grade transceivers cannot operate reliably
• Digital Optical Monitoring provides real-time access to five critical operating parameters: transmit optical power, receive optical power, laser bias current, transceiver temperature, and supply voltage, enabling proactive maintenance and link troubleshooting without external test equipment
• Hot-pluggable SFP+ footprint allows installation and removal while the host system remains powered, reducing maintenance windows and supporting field upgrades without network interruption
• 850nm VCSEL transmitter operating over OM3 multi-mode fibre delivers 300m reach with sufficient link budget for patch panel loss, connector mating cycles, and ageing margin in typical campus and data centre topologies
• MSA (Multi-Source Agreement) compliance guarantees mechanical fit, electrical interface, and digital diagnostic interface compatibility with Dell and third-party networking platforms using industry-standard SFP+ cages

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we"ll deliver a replacement part before you return the faulty item,minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: 407-BBZM-BCC
Compatible Replacement For: 407-BBZM
Compatibility: Dell compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP+
Data Rate: 10 Gbps
Standard: 10GBASE-SR (IEEE 802.3ae)
Wavelength: 850nm
Fibre Type: Multi-mode (MMF)
Connector Type: Duplex LC
Max Reach: 300m on OM3 fibre (per datasheet, subject to fibre and link conditions)
DOM Support: Yes (Digital Optical Monitoring)
Operating Temperature: -40°C to 85°C (Industrial/Rugged)
Compliance: SFF-8431, SFF-8472, MSA

FAQs

Q: Will this work in place of the Dell 407-BBZM?
A: Yes. The 407-BBZM-BCC is a direct replacement for the Dell 407-BBZM. It conforms to the same 10GBASE-SR standard, uses the same SFP+ form factor, operates at the same 10 Gbps data rate, and provides identical 850nm optical output over multi-mode fibre. It is plug-and-play compatible with Dell equipment that supports the 407-BBZM.

Q: Which Dell platforms support this transceiver?
A: This transceiver works in any Dell switch, router, or server with an SFP+ port and 10GBASE-SR support. Confirmed compatible platforms include Dell PowerEdge R430, R440, R530, R540, R630, R640, R730, R740, R740xd, R940, T430, T440, T630, T640, and Dell Networking switches supporting SFP+ 10GbE optics. If your Dell device has an SFP+ cage and supports 10GBASE-SR, this module will function.

Q: What fibre type and reach does this support, and does the 300m apply to all multi-mode fibre?
A: This transceiver operates over OM3 or OM4 multi-mode fibre with 850nm wavelength. Maximum reach is 300m on OM3 fibre and can extend further on OM4. Older OM1 and OM2 fibres will work but at reduced distances (typically 33m and 82m respectively). The duplex LC connector requires standard LC-terminated fibre patch cables.

Q: How does the industrial temperature range differ from standard SFP+ transceivers, and when is it needed?
A: Standard commercial-grade SFP+ transceivers operate from 0°C to 70°C. This industrial version extends the range to -40°C to 85°C using hardened VCSEL lasers, temperature-compensated drive circuits, and ruggedised optical components. This range is essential for outdoor cabinet installations, factory floors without climate control, mining infrastructure, and transportation systems where ambient temperature exceeds commercial limits.

Q: Can I access DOM data, and what parameters are available?
A: Yes, DOM (Digital Optical Monitoring) is supported via the SFF-8472 interface. You can query transmit power (dBm), receive power (dBm), laser bias current (mA), transceiver internal temperature (°C), and supply voltage (V) in real time using show interface transceiver commands or SNMP on Dell switches. Thresholds for alarm and warning levels are programmed into the transceiver EEPROM for automated link health monitoring.
