Moxa EDS-408A | 8-Port Managed Industrial Switch, 10/100, DIN-Rail

Authorised Moxa Partner

SKU:EDS-408A

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa EDS-408A is an entry-level Layer 2 managed industrial Ethernet switch with 8 x 10/100BaseT(X) RJ45 ports and no fibre ports. Built for factory automation, transport and utility networks, it combines Turbo Ring and Turbo Chain redundancy with VLAN, QoS and IGMP snooping, and this standard model operates across -10 to 60°C.

Redundant dual 12/24/48 VDC power inputs, an IP30 metal housing and DIN-rail mounting suit control cabinet installations. Management is available through a web browser, CLI, Telnet and serial console, SNMPv1/v2c/v3 and the MXstudio industrial network management suite, with EtherNet/IP and Modbus TCP support for device monitoring.

Features

- Turbo Ring and Turbo Chain with recovery time under 20 ms at 250 switches, plus RSTP/STP
- IGMP snooping, IEEE 802.1Q VLAN and port-based VLAN
- QoS using IEEE 802.1p and TOS/DiffServ
- GVRP to simplify network planning
- Port mirroring for online debugging
- RMON for proactive network monitoring
- Bandwidth management to prevent unpredictable network conditions
- DHCP Option 82 for flexible IP address assignment policies
- EtherNet/IP and Modbus TCP support for device management and monitoring
- SNMPv1/v2c/v3, HTTPS/SSL and SSH for secure management
- Port lock, trusted access control and broadcast storm protection
- Managed through web browser, CLI, Telnet/serial console, Windows utility, ABC-01 and MXstudio

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x 10/100BaseT(X) RJ45 ports with auto-negotiation, full/half duplex and auto MDI/MDI-X
- No fibre ports
- Layer 2 managed switch
- MAC table size: 8K
- Up to 64 VLANs, VLAN ID range 1 to 4094
- Packet buffer: 1 Mbit
- 4 priority queues, 256 IGMP groups
- RS-232 console port (10-pin RJ45)
- Relay alarm output, 1 A @ 24 VDC
- Redundant dual 12/24/48 VDC inputs, 9.6 to 60 VDC operating range
- Input current: 0.61 A @ 12 VDC, 0.3 A @ 24 VDC, 0.16 A @ 48 VDC
- Overload current and reverse polarity protection
- Operating temperature: -10 to 60°C
- Storage temperature: -40 to 85°C
- Humidity: 5 to 95% non-condensing
- IP30 metal housing
- Dimensions: 53.6 x 135 x 105 mm, weight 650 g
- DIN-rail mounting, wall mounting with optional kit
- Certifications include UL 508, EN 62368-1, EN 50121-4, ATEX, Class I Division 2 and IECEx

FAQs

Q: Does the EDS-408A have fibre ports?
A: No. This model provides 8 x 10/100BaseT(X) RJ45 copper ports only, with no fibre uplinks.

Q: What is the operating temperature range?
A: This standard model operates from -10 to 60°C. It is not the wide temperature variant.

Q: What power supply does it use?
A: It has redundant dual 12/24/48 VDC inputs on a removable 6-contact terminal block, with a 9.6 to 60 VDC operating range. A DC power supply is required.

Q: Which network redundancy protocols are supported?
A: Moxa Turbo Ring and Turbo Chain, with recovery under 20 ms at 250 switches, as well as RSTP/STP.

Q: How can it be mounted?
A: It mounts on a DIN rail as standard, and wall mounting is possible with the optional kit.

Q: Can it be managed with industrial protocols?
A: Yes. It supports EtherNet/IP and Modbus TCP for device management and monitoring, and can be managed with Moxa's MXstudio software.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
