Teltonika RUTM09 | 4G LTE Cat 6 Router, Dual SIM, 4x Gigabit, GNSS

Authorised Teltonika Partner

SKU:RUTM09

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Teltonika RUTM09 is a wired 4G LTE Cat 6 router with dual SIM failover, carrier aggregation and four Gigabit Ethernet ports. It delivers up to 300 Mbps download and 50 Mbps upload over cellular, with 3G fallback, making it well suited to primary or backup internet connectivity for branch offices, retail sites, remote installations and vehicles. Built-in GNSS adds location services and time synchronisation.

The RUTM09 has no built-in Wi-Fi, so it suits wired deployments where LAN devices connect directly or through a downstream switch or access point. Up to 128 tag and port-based VLANs allow network segmentation, and the router can be managed remotely through Teltonika RMS. It supports DIN-rail, wall and flat-surface mounting with additional kits, and includes an 18W power supply.

Features

- Carrier aggregation and dual-SIM failover for uninterrupted high-throughput data
- GNSS location services and time synchronisation
- Remote management via Teltonika RMS (Remote Management System)
- Port-based and tag-based VLAN support
- Manufactured in Europe

Warranty

Teltonika networking products come with a 24-month warranty from the date of purchase. Batteries are covered under a separate 6-month warranty.
https://teltonika-networks.com/support/warranty-repair

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 4G LTE Cat 6: up to 300 Mbps download / 50 Mbps upload
- 3G fallback: up to 42 Mbps download / 5.76 Mbps upload
- Dual SIM (2 x Mini SIM 2FF) with auto-switching and failover
- 4 x 10/100/1000 Mbps Gigabit RJ45 Ethernet ports (IEEE 802.3, 802.3u, 802.3az, auto MDI/MDIX)
- 1 x USB-A port
- GNSS/GPS support
- Up to 128 tag and port-based VLANs
- 2 x SMA mobile antenna connectors, 1 x SMA GNSS antenna connector
- 18W power supply included
- Mounting: DIN-rail, wall mount or flat surface (additional kits required)
- No Wi-Fi (wired only)

FAQs

Q: Does the Teltonika RUTM09 have Wi-Fi?
A: No. The RUTM09 is a wired-only router. Connect devices to its four Gigabit Ethernet ports directly, or add a switch or access point for wireless coverage.

Q: What cellular speeds does the RUTM09 support?
A: It supports 4G LTE Cat 6 with up to 300 Mbps download and 50 Mbps upload, with 3G fallback of up to 42 Mbps download and 5.76 Mbps upload.

Q: Does the RUTM09 support dual SIM failover?
A: Yes. It has two Mini SIM (2FF) slots with automatic switching, so it can fail over to the second SIM if the primary connection drops.

Q: Can the RUTM09 be managed remotely?
A: Yes. It supports Teltonika RMS (Remote Management System) for remote monitoring and configuration of deployed routers.

Q: How can the RUTM09 be mounted?
A: It can be DIN-rail mounted, wall mounted or placed on a flat surface. The DIN-rail and wall mount options require additional kits.

Q: Does the RUTM09 include GPS?
A: Yes. It includes GNSS support with a dedicated SMA GNSS antenna connector for location services and time synchronisation.
