Teltonika RUT300 | Industrial Router, 5-Port Fast Ethernet, DIN Rail

Name: Teltonika RUT300 | Industrial Router, 5-Port Fast Ethernet, DIN Rail
Brand: Teltonika
SKU: RUT300
Price: 137.85 AUD
Availability: InStock

Authorised Teltonika Partner

SKU:RUT300

In stock:8

$137.85 inc. GST

$125.32 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Teltonika RUT300 is a compact industrial Ethernet router with five 10/100 Mbps ports (1 WAN, 4 LAN), built for reliable wired connectivity in harsh environments. Housed in an aluminium DIN-rail enclosure and rated for -40 C to 75 C operation, it suits remote sites, cabinets, kiosks and industrial automation deployments.

The RUT300 runs RutOS, an OpenWrt based operating system, with a firewall, multiple VPN options, multi-WAN load balancing and automatic failover. Two configurable digital I/O pins, a USB 2.0 port with Samba share and passive PoE input on a LAN port add flexibility, while Teltonika RMS provides remote management of fleets of devices.

Features

- Compact industrial Ethernet router
- Multiple VPN support
- Multi-WAN load balancing and automatic failover
- Passive PoE support on LAN port
- Configurable digital I/O pins
- Aluminium housing with DIN rail mounting
- Wide operating temperature range (-40 C to 75 C)
- USB 2.0 with Samba share
- Remote management via Teltonika RMS
- Dynamic routing including BGP, OSPFv2, RIPv1/v2, EIGRP and NHRP
- Firewall with port forwarding, traffic rules, DMZ and NAT
- RutOS (OpenWrt based) operating system

Warranty

Teltonika networking products come with a 24-month warranty from the date of purchase. Batteries are covered under a separate 6-month warranty.
https://teltonika-networks.com/support/warranty-repair

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 5 x 10/100 Mbps Ethernet ports (1 x WAN, 4 x LAN)
- LAN ports can be configured as secondary WAN
- CPU: QCA9531, MIPS 24kc, 650 MHz
- RAM: 64 MB DDR2
- Flash: 16 MB SPI Flash
- Operating system: RutOS (OpenWrt based Linux OS)
- Power input: 4-pin DC socket, 7-30 VDC
- Passive PoE input: 9-30 VDC on LAN port
- Power consumption: 1.3 W idle, 3 W maximum
- 2 x configurable digital I/O on 4-pin socket (open collector output, max 30 V, 300 mA)
- USB 2.0 for external devices, Samba share
- Status LEDs: 5 x Ethernet, 1 x Power
- Aluminium housing with DIN rail or flat surface mounting
- Dimensions (W x H x D): 100 x 30 x 85 mm
- Weight: 229 g
- Operating temperature: -40 C to 75 C
- Operating humidity: 10% to 90% non-condensing
- Ingress protection: IP30
- Package contents: RUT300 router, 9 W PSU, 1.5 m Ethernet cable, QSG, RMS flyer, packaging box

FAQs

Q: How many Ethernet ports does the RUT300 have and what speed are they?
A: The RUT300 has five 10/100 Mbps Ethernet ports, one WAN and four LAN. The LAN ports can be configured as a secondary WAN.

Q: Does the RUT300 support PoE?
A: It supports passive PoE input (9-30 VDC) on a LAN port, so it can be powered over Ethernet from a compatible passive PoE source. It is a powered device only and does not supply PoE to other devices.

Q: What operating temperature range does the RUT300 support?
A: The RUT300 operates from -40 C to 75 C with 10% to 90% non-condensing humidity, and its aluminium housing is rated IP30.

Q: How can the RUT300 be mounted?
A: It can be mounted on a DIN rail or placed on a flat surface. The enclosure measures 100 x 30 x 85 mm and weighs 229 g.

Q: Does the RUT300 include a cellular modem or Wi-Fi?
A: No, the RUT300 is a wired Ethernet router. Connectivity is provided by its WAN and LAN Ethernet ports, with multi-WAN load balancing and failover across wired WAN connections.

Q: What can the digital I/O pins be used for?
A: The 4-pin power socket provides two configurable digital I/O pins, with an open collector output (max 30 V, 300 mA) and an input (0-6 V low, 8-30 V high), useful for simple sensing and control tasks.
