Moxa

Moxa BST-1220-T | BST-1000 Industrial 5G Signal Booster, n79, 5x SMA, IP30

Moxa BST-1220-T | BST-1000 Industrial 5G Signal Booster, n79, 5x SMA, IP30

Authorised Moxa Partner

BST-1220-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa BST-1220-T is an industrial 5G signal booster for the n79 band, designed to amplify and extend the Tx/Rx capability of connected 5G user equipment. It counters signal attenuation, interference and cable loss in low-power 5G environments, using five female SMA antenna connectors and a front-panel T/Rx LED for at-a-glance status.

Built for industrial deployments, the BST-1220-T has a rugged metal IP30 housing and operates from -40 to 70°C on a 9 to 24 VDC supply. Its compact footprint suits DIN-rail mounting, with optional wall mounting, and it integrates easily with Moxa 5G user equipment.

Features

- Stabilises and improves low-power 5G signal environments
- Easy integration with Moxa 5G user equipment
- Compact size for easy installation
- 40 to 70°C wide-temperature design

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Frequency band supported: n79
- Cellular antenna connectors: 5 x SMA (female)
- LED indicators: Power, Ready, T/Rx
- Input power: 9 to 24 VDC
- Dimensions: 116.3 x 96.8 x 24.7 mm (4.58 x 3.81 x 0.97 in)
- Housing: Metal
- IP rating: IP30
- Weight: 370 g (0.816 lb)
- Installation: DIN-rail mounting; wall mounting (with optional kit)
- Operating temperature: -40 to 70°C (-40 to 158°F)
- Storage temperature: -40 to 85°C (-40 to 185°F)
- Ambient relative humidity: 5 to 95% (non-condensing)

FAQs

Q: Which 5G band does the BST-1220-T support?
A: The BST-1220-T supports the n79 band.

Q: What antenna connectors does it use?
A: It has 5 x SMA (female) cellular antenna connectors.

Q: What power supply does the BST-1220-T require?
A: It operates from a 9 to 24 VDC input.

Q: How is the BST-1220-T mounted?
A: It supports DIN-rail mounting, and wall mounting is available with an optional kit.

Q: What operating temperature range does it cover?
A: It operates from -40 to 70°C, suiting harsh industrial environments.

Q: What do the LED indicators show?
A: The front panel has Power, Ready and T/Rx LEDs for quick status checks.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
