Moxa AWK-4131A-EU-T | AWK-4131A Outdoor Wi-Fi 4 Access Point, EU Band, -40 to 75C

Authorised Moxa Partner

SKU:AWK-4131A-EU-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa AWK-4131A-EU-T is an outdoor industrial Wi-Fi 4 (802.11a/b/g/n) access point, bridge and client for the EU band, built for harsh sites that need a dependable wireless link. It supports selectable dual-band 2.4/5 GHz operation at up to 300 Mbps with 2x2 MIMO, in an IP68-rated metal enclosure with a -40 to 75C operating range.

A single Gigabit PoE port, two N-type antenna connectors for external 3/6 dBi omni-directional antennas and redundant 12 to 48 VDC power inputs make it flexible to deploy. Turbo Roaming delivers sub-150 ms recovery in Client mode, 5 GHz DFS channels help avoid interference, and the unit is supported by MXview Wireless, MXconfig and MXview One for network management.

Features

- IEEE 802.11n Wi-Fi 4 AP, bridge and client in one device
- Selectable dual-band Wi-Fi with data rates up to 300 Mbps
- 2x2 MIMO for improved multi-stream transmission and reception
- 5 GHz DFS channel support to avoid wireless interference
- IP68-rated weatherproof housing with -40 to 75C operating range
- Power and antenna port isolation for enhanced ESD and surge protection
- Turbo Roaming with sub-150 ms recovery in Client mode
- Supported by MXview Wireless network management software
- Compliant with EN 18031-1 for EU regulatory alignment and cybersecurity

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- IEEE 802.11a/b/g/n, selectable dual-band 2.4/5 GHz, up to 300 Mbps
- 2x2 MIMO
- EU band: 2.4 GHz 13 channels; 5 GHz with DFS
- Transmit power (EU): 18 dBm at 2.4 GHz, up to 23 dBm at 5 GHz
- 1 x 10/100/1000BaseT(X) PoE port (RJ45)
- 2 x N-type female antenna connectors, external 3/6 dBi omni-directional antennas
- WLAN operation modes: Access point, Client, Client-Router, Master, Slave, Sniffer
- Wireless security: WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise (802.1X/RADIUS)
- Console port: RS-232, 8-pin RJ45
- Relay output alarm contact, 1 A @ 24 VDC
- Housing: IP68 metal
- Dimensions: 224 x 147.7 x 66.5 mm
- Weight: 1,400 g
- Input voltage: 12 to 48 VDC redundant dual inputs, 48 VDC PoE
- Power connector: M12 A-coded 5-pin male
- Power consumption: 7.68 W max.
- Operating temperature: -40 to 75C
- Installation: wall mounting (standard), DIN-rail or pole mounting (optional)

FAQs

Q: Is the AWK-4131A-EU-T suitable for outdoor installation?
A: Yes. It has an IP68-rated metal housing and an operating temperature range of -40 to 75C, so it suits outdoor and harsh industrial environments.

Q: Which wireless modes does it support?
A: It supports Access point, Client, Client-Router, Master, Slave and Sniffer modes, so one model can serve as an AP, bridge or client.

Q: How can it be powered?
A: It accepts 12 to 48 VDC through redundant dual inputs, or 48 VDC Power over Ethernet through its Gigabit PoE port.

Q: Does it come with antennas?
A: It provides two N-type female connectors for external 3/6 dBi omni-directional antennas. Confirm the antenna requirement for your deployment when ordering.

Q: What frequency bands and speeds does it support?
A: This EU-band model supports selectable 2.4 GHz and 5 GHz operation, including DFS channels, at up to 300 Mbps with 2x2 MIMO.

Q: How is it mounted?
A: Wall mounting is standard. DIN-rail and pole mounting are available as optional extras.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
