Description

The Moxa AWK-3262A-UN-T is an industrial Wi-Fi 6 (IEEE 802.11ax) wireless AP, bridge and client built for harsh environments. It delivers concurrent dual-band 2.4 GHz and 5 GHz operation with aggregated data rates up to 1.775 Gbps, and pairs one 10/100/1000/2500BaseT(X) port with one 10/100/1000BaseT(X) port in an IP30 housing. This UN band model carries the -T wide temperature rating, operating from -40 to 75°C.

Wi-Fi 6 OFDMA and Spatial Reuse support multi-client communication in high-density environments, while AeroMesh provides an adaptive, self-forming, self-healing and controller-agnostic mesh network. Built-in 2.4 GHz and 5 GHz band pass filters and power and antenna port isolation improve link reliability and ESD/surge protection, and the unit remains backward compatible with 802.11a/b/g/n/ac clients.

Features

- Wi-Fi 6 OFDMA and Spatial Reuse for multi-client communication in high-density environments
- AeroMesh adaptive, self-forming, self-healing, controller-agnostic mesh network
- Built-in 2.4 GHz and 5 GHz band pass filters for more reliable wireless connections
- Power and antenna port isolation for enhanced ESD/surge protection
- Security features referencing IEC 62443-4-2 Security Level 2
- Operates as an access point, bridge or client

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 6 (IEEE 802.11ax) concurrent dual-band, 2.4 GHz and 5 GHz
- Aggregated data rates up to 1.775 Gbps
- 1 x 10/100/1000/2500BaseT(X) port and 1 x 10/100/1000BaseT(X) port
- UN band: 2.412-2.472 GHz (13 channels), 5.180-5.240 GHz (4 channels), 5.260-5.320 GHz (4 channels), DFS support in AP mode
- 2.4 GHz: 802.11ax with 1024 QAM, 20/40 MHz channel width
- 5 GHz: 802.11ax with 1024 QAM, 20/40/80 MHz channel width
- IP30 rated housing
- Operating temperature -40 to 75°C (wide temperature -T model)
- Backward compatible with 802.11a/b/g/n/ac/ax

FAQs

Q: What operating modes does the AWK-3262A-UN-T support?
A: It can operate as a wireless access point, bridge or client, which suits both infrastructure and point-to-point industrial links.

Q: What temperature range does this model support?
A: The -T wide temperature variant operates from -40 to 75°C, making it suitable for outdoor cabinets, mining, transport and other harsh sites.

Q: What does the UN band designation mean?
A: The UN band model covers 2.412-2.472 GHz (13 channels) and 5.180-5.320 GHz across two 4-channel groups, with DFS support in AP mode. Confirm that the band suits your region before deployment.

Q: Which Ethernet ports does it have?
A: It has one 10/100/1000/2500BaseT(X) port and one 10/100/1000BaseT(X) port, so a multi-gigabit uplink can carry the full aggregated wireless throughput.

Q: Will it work with older Wi-Fi clients?
A: Yes. It is backward compatible with 802.11a/b/g/n/ac clients as well as 802.11ax devices.

Q: Can it form a mesh network?
A: Yes. AeroMesh creates an adaptive, self-forming, self-healing and controller-agnostic mesh network for roaming and redundant wireless backhaul.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
