Juniper QFX5200-32C-LAFO | QFX5200 1U Switch, AC, AFO, Junos Evolved, 32x 100GbE QSFP28

Authorised Juniper Partner

SKU:QFX5200-32C-LAFO

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Juniper QFX5200-32C-LAFO is a 1U, 32-port 100GbE QSFP28 data centre switch for high-density top-of-rack, access and aggregation deployments. This AC-powered, airflow-out (AFO) variant ships with Junos OS Evolved and delivers up to 6.4 Tbps of system throughput.

Each port supports 100GbE or 40GbE QSFP+ at line rate, with breakout options to 10GbE and 25GbE. The compact 1U footprint suits dense spine-leaf fabrics where rack space and port density are priorities.

Features

- 32 ports of 100GbE or 40GbE at line rate for high-density fabric deployments
- Suited to top-of-rack and data centre access and aggregation roles
- Runs Junos OS Evolved
- Breakout cabling support for 10GbE and 25GbE connectivity
- Compact 1U design to maximise rack density

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 32 x 100GbE QSFP28 ports, also supports 40GbE QSFP+
- Up to 6.4 Tbps system throughput (bi-directional)
- Up to 3.2 Bpps forwarding capacity
- 1U form factor
- AC power supplies
- AFO (airflow out) cooling
- Breakout support to 10GbE and 25GbE
- Junos OS Evolved

FAQs

Q: What does AFO mean on the QFX5200-32C-LAFO?
A: AFO stands for airflow out. The fans exhaust air from the port side of the switch, so the airflow direction must match your rack's hot and cold aisle layout.

Q: Does this switch run Junos OS Evolved?
A: Yes. The QFX5200-32C-LAFO is the variant supplied with Junos OS Evolved.

Q: What port speeds does the QFX5200-32C support?
A: It has 32 QSFP28 ports that run at 100GbE or 40GbE, with breakout support to 10GbE and 25GbE using suitable breakout cabling.

Q: What is the switching capacity?
A: The QFX5200-32C provides up to 6.4 Tbps of bi-directional system throughput and up to 3.2 Bpps of forwarding capacity.

Q: Is this switch AC or DC powered?
A: This LAFO model uses AC power supplies.

Q: What deployments is it suited to?
A: It is designed for high-density data centre top-of-rack, access and aggregation deployments, including spine-leaf fabrics.
